6.
Connect the Intra cables to the Generator PCB according to the figure below.
7.
Attach the generator housing to the generator assembly with three M4x6 ULS screws.
Installation instructions
P1
P8
PLANMECA INTRA X-RAY UNIT
Planmeca Intra Mobile base 5/8
