9.2 J452 Connections

PAC45 Connector, J452
COM 1
COM 2
COM 3
COM 4
COM 5
VHF NAV 1
VHF NAV 2
ADF 1
ADF 2
DME
MKR
UNSW 1
UNSW 2
Music Source
200-045-0100
PS Engineering
PAC45A Audio Selector Panel and Intercom System
Installation and Operator's Manual
Com 1 Audio Hi
Com 1 Lo
Com 2 Audio Hi
Com 2 Audio Low
Com 3 Audio Hi
Com 3 Audio Low
Com 4 Audio Hi
Com 4 Audio Low
Com 5 Audio Hi
Com 5 Audio Low
Nav 1 Audio Hi
Nav 1 Audio Lo
Nav 2 Audio Hi
Nav 2 Audio Lo
ADF 1 Audio Hi
ADF 1 Audio Lo
ADF 2 Audio Hi
ADF 2 Audio Lo
DME Audio Hi
DME Audio Lo
MKR Audio Hi
MKR Audio Lo
Unswitched Input #1 Hi
Unswitched Audio Lo
Unswitched Input #2 Hi
Unswitched Audio Lo
Music (Left)
Music (Right)
Music Lo
+28VDC Dimmer
Appendix E
P452
3
22
2
21
4
23
5
24
6
25
7
26
8
27
9
28
10
29
11
30
12
31
13
32
1
20
18
PIL PHN (L)
37 PIL PHN Low
COPIL PHN (L)
17
COPIL PHN Low
36
14
15
34
19
January 2020
Pilot Phones Jack
Copilot Phones Jack
