DEMO MANUAL DC1630A

PARTS LIST

ITEM QUANTITY
Required Circuit Components
1 1
2 1
3 1
4 6
5 1
6 4
7 2
8 1
9 1
10 1
11 1
12 1
13 1
14 1
Additional Demo Board Circuit Components
1 0
2 0
3 0
Hardware, for Demo Board Only
1 17
2 1
3 1
4 1
4
Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from
REFERENCE DESCRIPTION
C13 Capacitor, NPO, 100pF , 50V, 5%, 0603
C9 Capacitor, X7R, 0.1μF , 50V, 10%, 0603
C14 Capacitor, X7R, 22nF , 50V, 10%, 0603
C7, C8, C10, C11, C12, C15 Capacitor, X7R, 10μF , 10V, 1206
C16 Capacitor, X7S, 4.7μF , 10V, 0805
C2, C3, C4, C5 Capacitor, X7R, 22μF , 10V, 1210
C1, C6 CCapacitor X7R, 10μF , 100V, 20%, 2220
D1 Diodes, Barrier Rectifer
L1 Inductor, High Temperature
R6 Resistor, Chip, 0Ω 0603
R3 Resistor, Chip, 10k 5% 0603
R5 Resistor, Chip, 4.99k 1% 0603
R4 Resistor, Chip, 42.2k 1% 0603
U1 IC., Linear LTM8008HV LGA 15 × 15
C (TBD) Capacitor, Aluminum Electrolytic 100V
IN
D2 (Optional) Zener Diode, SOD523
R1, R2 (Optional) Resistor, Chip 0603
E1-E17 Turret, Testpoint
JP1 Header, 1 × 3 Pins, 2mm
JP1 Shunt, 2 Pins, 2mm
FAB, Printed Circuit Board
MANUFACTURERS PART NUMBER
AVX, 06035A101JAT2A
AVX, 06035C104KAT2A
AVX, 06035C223KAT2A
Murata, GCM31CR71A106KA64
Murata, GCM21BC71A475KA73
Murata, GCM32ER71A226KE12L
TDK, CKG57NX7R2A106MT
Diodes Inc., SBR3U100LP-7
Coilcraft, MSD1278T-472MLD
Vishay, CRCW06030000Z0EA
Vishay, CRCW060310K0JNEA
Vishay, CRCW06034K99FKED
Vishay, CRCW060342K2FKED
Linear Technology, LTM8008HV
Suncon, CE-PC Series
Mill-Max, 2501-2-00-80-00-00-07-0
Samtec, TMM-103-01-L-S
Samtec, 2SN-BK-G
Demo Circuit 1630A
dc1630af
