IMPORTANT NOTE

• Before and during installation, please read and familiarize yourself with all installation instructions for this product.
• Please keep all components, parts and accessories of this product away from small children and minors. During installation,
all screws,tools and small parts should be supervised so that they do not fall into the hands of children.
• Use caution at all times when installing this product. Please ensure that you are physically able to perform all parts of the
installation and that you have the correct tools and equipment needed.
• Before beginning,remove all wrappers and packinging materials including staples and packing straps.
• Please check to ensure that all components and parts are complete.
• The Filter Gasket (#12) must be installed to protect against incoming dirt by pipework. Incoming dirt can impair the function
and/or lead to damages on functional parts of the fixture. Manufacturer will not be held liable for resulting damages.
• The O Ring Gasket (# 13) must be installed to prevent water leakage. Manufacturer will not be responsible or liable from
any damage which results directly or indirectly from failure to installation of the O Ring Gasket.

RECOMMENDED TOOLS FOR INSTALLATION

-
+
PH
Screwdriver
Drill Bit 6mm
Electric Drill

PARTS LIST

NO. Description
Shower Arm
1
Shower Ring
2
3 Shower Head
Glass Shelf
4
Shower Panel Casing
5
6 Screw Anchor
Positioning and Support Brackets
7
8 Screws
9 Brass extender joint (1 5/8"& 2 5/8"x ½")
Handshower
10
11 Handshower Hose
12 Filter Gasket
O Ring Gasket
13
2.5 mm
Hexagon-wrench
24 mm /30mm
Wrenches
Hammer
Pliers
- 3 -
Level Sealing Tape
Vice
Pencil
Qty
1 pc
1 pc
1 pc
1 set
1 set
4 pcs
2 pcs
4 pcs
2 pcs
1 pc
1 set
3 pcs
1 pc
