Technical Data
Maximum operating pressure:
Recommended pressure:
Test pressure:
Flow rate @ 80 psi:
* For Safety, it is highly recommended that you familiarize yourself with all applicable local plumbing codes
before installing this product.
NOTE: Please turn on the Faucet first.
• Shower Head Position
When the position knob is placed in "a".
a
• Spray Position
When the position knob is placed in"c" .
c
How to use Diverter
• Hand Shower Position
When the position knob is placed in"b".
•
When the position knob is placed in between each
dot mark, this will result in a sharing of water output
between 2 operating modes .This can be used if
combination of 2 modes is desired however the
water output will be reduced due to sharing of
water flowing through the system between those 2
operating modes.
When the position knob is placed "d", the
handshower and the top hydro jets will work
simultaneously.
- 12 -
125psi
50~80psi
45 psi ,125psi
<2. gpm 0
Two modes simultaneously
d
