Summary of Contents for TechniSat Digitradio 510
-
Page 2: Important Safety Instructions
Important Safety Instructions 1. Read these instructions. 2. Keep these Instructions. 3. Heed all Warnings. 4. Follow all instructions. 5. Do not use the speaker near water. 6. Clean only with dry cloth. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS SPEAKER TO RAIN OR MOISTURE. -
Page 3: Table Of Contents
Contents Important Safety Instructions ......................2 Contents ............................3 Getting Started ..........................5 Unit Top View .......................... 7 Unit Front View ........................8 Unit Back View ......................... 8 Remote Control Overview ......................9 Setup Wizard ..........................10 Internet Radio Mode ........................12 Local Country Stations ...................... - Page 4 Scan settings ......................... 25 Audio Settings ........................25 Viewing Station Information ....................25 Storing Preset Stations ......................26 Recalling a Preset Station ..................... 26 Bluetooth Mode ..........................27 NFC (Near Field Communication) ....................27 Aux in Mode ..........................28 Wireless Device Remote Control App ................... 29 App installation ........................
-
Page 5: Getting Started
Getting Started Carefully remove your radio from the box. You may wish to store the packaging for future use. What you can find inside of your package Main unit Power adapter Remote control Instruction manual Positioning your Radio Place your radio on a flat / stable surface that is not subject to vibrations. Avoid the following locations: Where the radio will be exposed to direct sunlight. - Page 6 Using Headphones You will require headphones fitted with a 3.5 mm diameter stereo plug. The Headphones socket is located on the back of this unit. Headphones are not supplied with this radio. Turn down the volume before connecting earphones. Slowly raise the volume with the earphones on until you reach your desired level.
-
Page 7: Unit Top View
Unit Top View NFC sensor VOLUME/ knob Press to switch radio on or standby. Display Turn to adjust volume. DAB/FM antenna MODE button 10. BACK button Press to switch among Internet, Spotify, Press to return to previous menu screen. Music player, DAB, FM, Aux in and 11. -
Page 8: Unit Front View
Unit Front View Speaker Display Unit Back View DAB/FM antenna DC IN socket AUX IN socket Headphones socket... -
Page 9: Remote Control Overview
Remote Control Overview button Press to switch radio on or standby. OK button Press to confirm your selection. Navigation buttons down backward forward VOL +/- buttons Press to adjust volume. MENU button Press to display menu or exit menu. MODE button Press to switch among Internet, Spotify, Music player, DAB, FM, Bluetooth and Aux in modes. -
Page 10: Setup Wizard
Setup Wizard After setting the language, the display will show ‘Setup wizard’ screen. Press SELECT/TUNE knob to confirm ‘YES' to start setup. Options in the setup wizard include the following: Date/Time Set 12 or 24 hour format Auto update Update from DAB "... - Page 11 Turn SELECT/TUNE knob to cycle through the alphanumeric character list, press SELECT/TUNE knob to select an appointed character. Note: WEP/WPA pass codes are case-sensitive. If a wrong operation is being conducted, select to delete designated character. Note: = Backspace; means return to previous track; radio will automatically save the WEP/WPA you’ve input, so no bother to re-enter these codes.
-
Page 12: Internet Radio Mode
Internet Radio Mode The display will show 'Main menu' after 'Setup wizard' completed. Press SELECT/TUNE knob to select Internet radio mode. While 'Station list' is highlighted, press SELECT/TUNE knob to confirm. → Then refer following section to choice stations. Or if failed to connect to network, please follow: a. -
Page 13: Selecting A Station Through Podcasts
In 'Stations' menu: ‘Location’ enables you to choose from the radio stations provided by any country which you choose from a list. a. While 'Location' is highlighted, press SELECT/TUNE knob to confirm. b. Turn SELECT/TUNE knob to select the region you wanted, and then press SELECT/TUNE knob to confirm. -
Page 14: Adding Station To 'My Favourites
Adding station to ‘My Favourites’ To register your radio with the portal: www.wifiradio-frontier. com. Create account login, enter Access code is required. Access code can be found from “Station list > Help > Get access code". You can add your favourite stations via the portal (www. wifiradio-frontier.com). After you added the stations, in order to have your radio access your new settings, get your radio power off for several minutes is necessary. -
Page 15: Recalling A Preset Station
5. Preset number ‘ #’ will show on the display. Recalling a Preset Station Press PRESET button to show the saved preset stations. Turn SELECT/TUNE knob to select the preset station you want to play and then press the SELECT/TUNE knob to confirm. Alternatively, press one of Preset buttons 1-10 on the remote control to play the preset station. -
Page 16: Spotify Connect
Tap the square image of the song’s cover art in the bottom left of the screen. Then tap the Connect icon Tap ‘DigitRadio 510’ from the list. If you can’t see it, just check it’s connected to the same wifi network as your phone of tablet. - Page 17 The Connect icon will turn green to signify that DigitRadio 510 is now selected and being used for audio playback. Your Spotify app will only recognise DigitRadio 510 when the radio is connected to the internet (i.e. in Internet Radio, Spotify Connect or Music player modes). To use Spotify when your radio is in non-internet modes (i.e.
-
Page 18: Music Player Mode
Music player Mode Setting up a Music Server " In order for your radio play music files from a computer, the computer must be set up to share files or media. " UPnP media sharing allows devices like this radio to play music from a shared media library, navigating through tag menus such as Artist, Album or Genre. -
Page 19: Playing Shared Media
Playing Shared Media Press MODE button repeatedly to select Music player mode. While 'Shared media' is highlighted, press SELECT/TUNE knob to confirm, and then step by step to your selecting music. When a track is playing, you can: a. Press button to skip to previous track;... -
Page 20: Clearing My Playlist
Clearing My Playlist This feature enables you to clear the contents of your playlist. Press MENU button, turn SELECT/TUNE knob to select 'Clear My playlist', and then press SELECT/TUNE knob to confirm. Select 'YES' to clear my playlist. Prune Servers The Prune Servers feature enables you to remove music servers that are no longer available to you to browse for music. -
Page 21: Dab Mode
DAB Mode Selecting DAB Mode Press MODE button repeatedly to select DAB mode. For initial use, radio will carry out a full scan and store stations list in memory Once the scanning is completed, the DAB/DAB+ stations will be displayed in alphanumeric order. -
Page 22: Manual Tune
Manual Tune Press MENU button, turn SELECT/TUNE knob to select Manual tune, and then press SELECT/TUNE knob to confirm, the display will show the channel number and frequency. Turn SELECT/TUNE knob to step among the channels and then press SELECT/TUNE knob select the current channel. -
Page 23: Changing Station Order
Changing Station Order You may want to display the stations in different order. Press MENU button, turn SELECT/TUNE knob to select Station order, and then press SELECT/TUNE knob to confirm. Turn SELECT/TUNE knob to select 'Alphanumeric', 'Ensemble' or 'Valid', and then press SELECT/TUNE knob to confirm your selecting option. -
Page 24: Storing Preset Stations
Storing Preset Stations Your radio can store up to 10 of your favourite DAB/DAB+ stations. 1. While playing your favourite station, press and hold PRESET button on the main unit until diaplay shows as below: 2. Turn SELECT/TUNE knob to cycle through the preset stations store numbers 1-10. 3. -
Page 25: Fm Mode
FM Mode Selecting FM Mode 1. Press MODE button repeatedly to select FM mode. 2. For initial use, it will start at the beginning of the FM frequency range (87.50MHz). Otherwise, the last listened FM station will be selected. 3. To manually change the FM frequency, while FM frequency shows up, turn SELECT/TUNE knob clockwise or anticlockwise to change the frequency by 0.05MHz per step. -
Page 26: Storing Preset Stations
Storing Preset Stations Your radio can store up to 10 of your favourite FM stations. 1. While playing your favourite station, press and hold PRESET button on the main unit until diaplay shows as below: 2. Turn SELECT/TUNE knob to cycle through the preset stations store numbers 1-10. 3. -
Page 27: Bluetooth Mode
Activate your Bluetooth device and select the search mode. ‘DigitRadio 510’ will appear on your Bluetooth device. Select ‘DigitRadio 510’ and enter “0000” for the password if necessary. icon will remains steadily on the display when connection is successful. While a track is playing, you can:... -
Page 28: Aux In Mode
Aux in Mode AUX IN allows for quick and easy connection to an MP3 player or other external audio sources. Before connecting to the mains socket, use a 3.5mm audio cable (not supplied) to connect to your external audio device through the AUX IN socket on the back of unit. Connect power adapter to mains socket, press VOLUME/ knob to switch unit on. -
Page 29: Wireless Device Remote Control App
Once it is complete, you can access your new app. ‘MyDigitRadio’ App installation MyDigitRadio is an application that allows your iOS device to control your DigitRadio 510 radio. To install the MyDigitRadio App on your iOS device, type App Store icon on the iOS device to open the App store. -
Page 30: Setting Up The Connection
Choose the network of your radio accessed. Starting the Navigation Tap MyDigitRadio icon on the main menu of your iOS device, then start to navigate your DigitRadio 510 radio. In menu screen can find controls below: " Browse: allows you to browse mode menu of Internet radio, Music player or AUX in modes. -
Page 31: General Operation
General Operation Setting Sleep This feature enables your radio to switch to standby mode by itself after a set sleep time. Press MENU button > Main menu > Sleep, and then press SELECT/TUNE knob to confirm. Turn SELECT/TUNE knob to view options Sleep OFF, 15, 30, 45 or 60 MINS, press SELECT/TUNE knob to confirm. -
Page 32: Network Setup
Turn SELECT/TUNE knob and then press it to select Normal, Flat, Jazz, Rock, Movie, Classic, Pop, News, My EQ or My EQ profile setup. To set up My EQ, select 'My EQ profile setup ', and then press SELECT/TUNE knob to confirm. -
Page 34: Setting Language
Setting Language This feature enables you to change the language of displaying menu names. 1. Press MENU button > Main menu > System settings > Language, press SELECT/TUNE knob to confirm. 2. Turn SELECT/TUNE knob to select your language, and then press SELECT/TUNE knob to confirm. -
Page 35: Viewing System Info
Viewing System Info This information may be requested when dealing with technical support issues. 1. Press MENU button > Main menu > System settings > Info, press SELECT/TUNE knob to confirm. 2. Turn SELECT/TUNE knob to view 'SW version', ‘Spotify version’, 'Radio ID' and 'Friendly Name'. -
Page 36: Specifications
Specifications Items Specifications Internet, DAB/DAB+ and FM radio with Bluetooth and Spotify Description: Connect AC Input: 110-240Vac, 50-60 Hz Power Requirements: DC Output: 18V, 2A Audio Output Power: 10Wrms x 2 Power Consumption: 36W (Max) Dimension (W x H x D): 350mm x 115mm x 132mm This symbol on the product or in the instructions means that your electrical and electronic equipment should be...
