TechniSat DigitRadio 225 Instruction Manual

Dab/dab+ and fm digital radio with bluetooth
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading

Related Manuals for TechniSat DigitRadio 225

Summary of Contents for TechniSat DigitRadio 225

  • Page 2: Important Safety Instructions

    Important Safety Instructions 1. Read these instructions. 2. Keep these Instructions. 3. Heed all Warnings. 4. Follow all instructions. 5. Do not use the speaker near water. 6. Clean only with dry cloth. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS SPEAKER TO RAIN OR MOISTURE.
  • Page 3 carried out by qualified technicians. 16. The normal function of the product may be disturbed by strong Electro-Magnetic Interference. If so, simply reset the product to resume normal operation by following the instruction manual. In case the function could not resume, please use the product in other location. 17.

  • Page 4: Table Of Contents

    Contents Important Safety Instructions ......................2 Contents ............................4 Your radio ............................5 Getting Started ..........................6 DAB Mode ............................8 Scanning Stations ........................8 Manual Tune ..........................8 DRC (Dynamic Range Control) value ..................9 Selecting another Station ......................9 Secondary Service ........................

  • Page 5: Your Radio

    Your radio VOLUME/ knob Press to switch unit on or standby. Turn to adjust volume level. INFO/MENU button Press to view station information when a program is playing. Press and hold to display or exit menu screen. MODE button Press to switch among DAB, FM, Bluetooth and Aux in mode.

  • Page 6: Getting Started

    Getting Started Carefully remove your radio from the box. You may wish to store the packaging for future use. What you can find inside of your package Main unit Power adaptor Instruction manual Positioning your Radio Place your radio on a flat / stable surface that is not subject to vibrations. Avoid the following locations: Where the unit will be exposed to direct sunlight.
  • Page 7 Using Headphones You will require headphones fitted with a 3.5 mm diameter stereo plug. The Headphones socket is located at the rear of this unit. Headphones are not supplied with this radio. Turn down the volume before connecting headphones. Slowly raise the volume with the headphones on until you reach your desired level.

  • Page 8: Dab Mode

    DAB Mode When you turn on the radio it will automatically search and store all the available stations. You should conduct an additional Full Scan to ensure all stations are picked up and stored. It is also recommended every few months to run a new scan to pick up any new DAB/DAB+ that may have begun broadcasting after purchasing your DAB radio.

  • Page 9: Drc (Dynamic Range Control) Value

    DRC (Dynamic Range Control) value If you are listening to music with high dynamic range in a noisy environment (for example classical music while cooking), you may wish to compress the audio dynamic range. This makes quiet sounds louder and loud sounds quieter. 1.

  • Page 10: Viewing Station Information

    Viewing Station Information DAB/DAB+ stations broadcast additional information. Press INFO/MENU button repeatedly while a program is playing to view information through DLS (Dynamic Label Segment), Signal Strength, Program Type, Ensemble, Program Frequency, Signal Quality, Bitrate, Codec, Time and Date. Showing Signal Strength While you selected signal strength, a signal bar with the strength of the current station will show on the display.

  • Page 11: Fm Mode

    FM Mode Selecting FM Mode 1. Press MODE button repeatedly to select FM mode. 2. For initial use, it will start at the beginning of the FM frequency range (87.50MHz). Otherwise, the last listened FM station will be selected. 3. To manually change the FM frequency, while FM frequency shows up, turn SCROLL&SELECT/SNOOZE knob clockwise or anticlockwise to change the frequency by 0.05MHz per step.

  • Page 12: Viewing Station Information

    Viewing Station Information There is a variety of station information transmitted by broadcast, and this radio offers a convenient way for you to view them. To view currently playing station information, press INFO/MENU button repeatedly the display will show the information through Radio text, Program Type, Program Name, Audio info, Time and Date.

  • Page 13: Bluetooth Mode

    Activate your Bluetooth device and select the search mode. ‘DigitRadio 225’ will appear on your Bluetooth device. Select ‘DigitRadio 225’ and enter “0000” for the password if necessary. ‘BT connected: Your Bluetooth Device’ will show on the display when connection is successful.

  • Page 14: Aux In Mode

    Aux in Mode AUX IN allows for quick and easy connection to an MP3 player or other external audio sources. Before connecting to the mains socket, use a 3.5mm audio cable (not supplied) to connect to your external audio device through the AUX IN socket at the rear of unit. Connect power adaptor to mains socket, press VOLUME/ knob to switch unit on.

  • Page 15: General Operation

    General Operation Setting Sleep This feature enables your radio to switch to standby mode by itself after a set sleep time. Press and hold INFO/MENU button, and then turn SCROLL&SELECT/SNOOZE knob to select ‘Sleep’, press SCROLL&SELECT/SNOOZE knob to confirm. Turn SCROLL&SELECT/SNOOZE knob to select a sleep time, and then press SCROLL&SELECT/SNOOZE knob to confirm.

  • Page 16: Setting Equaliser

    Alarm duration time Snooze time 15 minutes 5 or 10 minutes 30 minutes 5, 10 or 15 minutes 45/60/90 minutes 5, 10, 15 or 30 minutes To turn off alarm, press VOLUME/ knob when the alarm sounds and then unit will go to standby.

  • Page 17: Setting Language

    Power on High Medium Standby High Medium Setting Language This feature enables you to change menu language. There are four languages available: English/ French/Italian/German. 1. Press and hold INFO/MENU button, and then turn SCROLL&SELECT/SNOOZE knob to select ‘Language’, press SCROLL&SELECT/SNOOZE knob to confirm. 2.

  • Page 18: Troubleshooting

    Troubleshooting If a problem occurs, it may often be due to something very minor. The following table contains various tips. Problem Solution How long do I charge the Keep mains power connecting and charge the battery for battery before first use? 12 hours before first time use.

  • Page 19: Specifications

    Specifications Items Specifications Description: DAB/DAB+ and FM digital radio with Bluetooth FM: 87.5-108 MHz Frequency Range: DAB/DAB+: 174.928-239.200 MHz AC Input: 110-240V~, 50-60 Hz Power Requirements: DC Output: 12V, 2000mA (please use our provided adaptor) Battery: 7.4V 5000mAh Audio Output Power: 5W rms x 2 Operation: 24W (Max) Power Consumption:...
