RED FOCUS OPERATION GUIDE
CHAPTER 1:
RED FOCUS INTRODUCTION
®
The RED Focus is a self-powered, illuminated PL mount diascope used to set PL backfocus/flange distance on the
®
RED ONE , EPIC, EPIC-W
on the camera when using the RED Focus.
Figure: RED Focus Package

RED FOCUS COMPONENTS

Each RED Focus package contains the following items:
RED Focus
®
REDVOLT AA (2-Pack)
RED Focus Case
C O PYR I G HT © 2 0 1 9 R ED.C O M , LLC
® ®
, SCARLET , WEAPON
® ®
, and SCARLET-W cameras. The PL mount must be installed
9 5 5 - 0 0 5 0 , R EV - L | 8
