RED FOCUS OPERATION GUIDE
CHAPTER 2:
RED FOCUS BASIC OPERATION
This section describes the physical control, indicator, and display of the RED

RED FOCUS FEATURES

Figure: RED Focus Features
# FEATURE
1 LED Indicator
2 Power Button
DISPLAY
The RED Focus projects a Siemens
C O PYR I G HT © 2 0 1 9 R ED.C O M , LLC
DESCRIPTION
When enabled, the LED illuminates green when turned on
Press to turn RED Focus on
®
star image onto the camera sensor for adjusting back focus.
®
Focus.
