- Page 1 Keysight U8903A Audio Analyzer Demonstration Procedure This document demonstrates five simple examples of using the U8903A. They are: – GUI intuitiveness and shallow menu tree – Loop test – FFT analysis – Time domain graph analysis – Frequency or amplitude sweep analysis...
- Page 2 02 | Keysight | Audio Analyzer Demonstration Procedure - Data Sheet 1. GUI Intuitiveness and Shallow Menu Tree Contents Demonstration Preparation Demo 1: GUI Intuitiveness and Shallow Menu Tree Demo 2: Loop Test Objective: Demo 3: FFT Analysis To demonstrate the features, capabilities, and intuitiveness of the Demo 4: Time Domain Graph Graphical User Interface (GUI) and menu tree.
- Page 3 03 | Keysight | Audio Analyzer Demonstration Procedure - Data Sheet PROCEDURE: Generator setup Press [Generator] to activate the Generator function. Use the arrow keys to select Channel 1 and Channel 2 of the Generator. Note: The active channel will be highlighted (see Figure 2).
- Page 4 04 | Keysight | Audio Analyzer Demonstration Procedure - Data Sheet PROCEDURE: 11. Function 1 indicates the first measurement parameter and Function 2 indicates the second measurement parameter. (Figure 4 shows that Function 1 refers to Frequency measurement while Function 2 refers to Vac measurement).
- Page 5 5 | Keysight | Audio Analyzer Demonstration Procedure - Data Sheet RESULTS: POINTS TO MENTION: – Easy to set up. – User-friendly GUI and very intuitive. – Shallow menu tree. – Custom filter can be saved, recalled, and created using MATLAB, Keysight VEE, and other programming software, and uploaded via USB, LAN, or GPIB.
- Page 6 6 | Keysight | Audio Analyzer Demonstration Procedure - Data Sheet 2. Loop Test Objective: To demonstrate the self-test feature of the audio analyzer. The Generator channel creates the signal and loops the signal to the Analyzer channel for measurements.
- Page 7 7 | Keysight | Audio Analyzer Demonstration Procedure - Data Sheet PROCEDURE: Analyzer setup Press [Analyzer] to activate the Analyzer function. You must activate the Analyzer Channel 1 by using the arrow key because the BNC connector is connected to the Analyzer Channel 1 .
-
Page 8: Fft Analysis
8 | Keysight | Audio Analyzer Demonstration Procedure - Data Sheet 3. FFT Analysis Objective: To demonstrate the FFT analysis features in the audio analyzer. PREREQUISITE: Switch [ON] the equipment. If you have a large crowd and a project/PC monitor is available in the meeting room, connect the VGA cable (from the projector/ PC monitor input) to the VGA output from the equipment as shown in Figure 1. - Page 9 9 | Keysight | Audio Analyzer Demonstration Procedure - Data Sheet PROCEDURE: Frequency domain setup Press [Frequency Domain] Press [Monitor settings] to change the graph monitor settings (see Figure 10). Ensure that the Channel 1 box is checked. Press DOWN arrow key and the monitor settings will be highlighted sequentially (that is the Analysis Mode, Windows, etc).
- Page 10 10 | Keysight | Audio Analyzer Demonstration Procedure - Data Sheet RESULTS: Press [Harmonics View] to display the level of each signal harmonic component of the frequency do- main analysis. You may configure the fundamental frequency, select the channel, and enter the number of harmonic components data that will be computed in the table.
- Page 11 11 | Keysight | Audio Analyzer Demonstration Procedure - Data Sheet 4. Time Domain Graph Analysis Objective: To demonstrate the Time Domain graph analysis (Scope) features in the audio analyzer. PREREQUISITE: Switch [ON] the equipment. If you have a large crowd and a project/PC monitor is available in the meeting room, connect the VGA cable (from the projector/ PC monitor input) to the VGA output from the equipment as shown in Figure 1.
- Page 12 12 | Keysight | Audio Analyzer Demonstration Procedure - Data Sheet PROCEDURE: TIME DOMAIN setup Press [Time Domain] Press [Monitor settings] to change the graph monitor settings (see Figure 15). Ensure that the Channel 1 box is checked. Press DOWN arrow key and monitor settings will be highlighted (that is, first the Analysis Mode and then Window).
- Page 13 13 | Keysight | Audio Analyzer Demonstration Procedure - Data Sheet 5. Frequency or Amplitude Sweep Analysis Objective: To demonstrate the Frequency or Amplitude Sweep analysis features in the audio analyzer. PREREQUISITE: Switch [ON] the equipment. If you have a large crowd and a project/PC monitor is available in the meeting room, connect the VGA cable (from the projector/ PC monitor input) to the VGA output from the equipment as shown in Figure 1.
- Page 14 14 | Keysight | Audio Analyzer Demonstration Procedure - Data Sheet PROCEDURE: SWEEP setup Press [Sweep] Press [Sweep settings] to change the sweep settings (see Figure 19). Press RIGHT arrow key to highlight the Sweep settings (that is, Sweep Parameter). Press [ENTER] to activate the drop-down menu from the Sweep Parameter and select Amplitude.
- Page 15 15 | Keysight | Audio Analyzer Demonstration Procedure - Data Sheet RESULTS: POINTS TO MENTION: – You should be able to see a straight line graph, because a loop test is being per- formed to measure the amplitude of the generator signal.
- Page 16 16 | Keysight | Audio Analyzer Demonstration Procedure - Data Sheet Evolving Since 1939 For more information on Keysight Technologies’ products, applications or Our unique combination of hardware, software, services, and people can help you services, please contact your local Keysight reach your next breakthrough.
