- Page 1 Keysight U1731C/ U1732C/U1733C Handheld LCR Meter Quick Start Guide...
- Page 2 Do not information) proceed beyond a CAUTION notice until the indicated conditions are fully understood and met. For further safety information details, refer to the Keysight U1731C/U1732C/U1733C Handheld LCR Meter User’s Guide. Keysight U1731C/U1732C/U1733C Quick Start Guide...
- Page 3 Keysight Sales Office. The descriptions and instructions in this guide apply NOTE to the U1731C, U1732C, and U1733C handheld LCR meters. The model U1733C appears in all illustrations. All related documents and software are available for download at www.keysight.com/find/hhTechLib.
-
Page 4: Install The Batteries
2 Lift the tilt stand and loosen the screw with a suitable Phillips screwdriver. 3 Remove the battery cover and observe the polarity markings. 4 Insert the battery and replace the battery cover and screw. Keysight U1731C/U1732C/U1733C Quick Start Guide... -
Page 5: Turn On The Lcr Meter
Discharge the capacitor before testing. Your LCR meter is capable of remote data logging. NOTE To use this feature, you will need an IR-USB cable (U5481A, purchased separately) and the Keysight GUI Data Logger Software (downloadable from www.keysight.com/find/hhTechLib). Keysight U1731C/U1732C/U1733C Quick Start Guide... -
Page 6: The Lcr Meter At A Glance
Tilt stand Battery cover (Lift the tilt stand for access) External power adapter input jack (+12 VDC) The external AC to DC power adapter input jack NOTE requires an input voltage of +12 VDC. Keysight U1731C/U1732C/U1733C Quick Start Guide... -
Page 7: Understanding The Keypad
[a] Autoranging only. ESR mode exits to capacitance (C) measurement by default. [b] Applicable for U1733C model only. DCR mode exits to inductance (L) measurement by default. [c] Applicable for U1732C and U1733C models only. Keysight U1731C/U1732C/U1733C Quick Start Guide... -
Page 8: Performing Lcr Measurements
Ai mode is enabled. – flashes when the LCR meter is identifying a measurement function and mode. – Press again while is shown to exit the Ai mode. LCR measurement steps Keysight U1731C/U1732C/U1733C Quick Start Guide... - Page 9 Secondary (D/Q/θ) measurements Inductance (L) measurements Inductor Capacitance (C) measurements Capacitor Resistance (R) measurements Resistor Keysight U1731C/U1732C/U1733C Quick Start Guide...
- Page 10 THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK. Keysight U1731C/U1732C/U1733C Quick Start Guide...
- Page 11 This information is subject to change without notice. Always refer to the Keysight website for the latest revision. © Keysight Technologies 2011-2017 Edition 5, July 1, 2017 Printed in Malaysia *U1731-90070* U1731-90070 www.keysight.com...
