9) PARTS LIST

Ref. No. Part No. Description.
1 Q230-001 SET FLUTE COVER
2 Q230-002 PIVOT
3 Q230-003 GLASS
4 Q230-004 DUST COVER SET
5 Q230-005 DUST COVER HOOK PLATE
6 Q230-006 LOCK WASHER
7 Q230-007 BOLT,M4X0.7,10MM,PAN HEAD,PHILLIPS
8 Q230-008 FLAT HD SCREW
9 Q230-009 DUST COVER PLATE
10 Q230-010 FLAT HD SCREW
11 Q230-011 ARBOR BOLT(BLADE BOLT)
12 Q230-012 FLANGE
14 Q230-014 O-TYPE RING
15 Q230-015 WASHER
16 Q230-016 BLADE WASHER
17 Q230-017 SPACER RING
18 Q230-018 EXTL RETAINING RING
19 Q230-019 WASHER
20 Q230-020 GUARD LOWER
21 Q230-021 BOLT,M4X0.7,10MM,PAN HEAD,PHILLIPS
22 Q230-022 LOCK WASHER
23 Q230-023 INNER BLADE GUARD
24 Q230-024 SCREW (SELF-TAPPING, CLAMP)
25 Q230-025 SCREW
26 Q230-026 SPRING
27 Q230-027 BOLT, FLAT HD
28 Q230-028 SCREW (SELF-TAPPING, CLAMP)
29 Q230-029 SCREW (SELF-TAPPING, CLAMP)
30 Q230-030 UPPER GUARD
31 Q230-031 SELF TAPPING SCREW
32 Q230-032 TORSION SPRING
33 Q230-033 BLADE GUARD LIFTER
34 Q230-034 FLAT WASHER
35 Q230-035 LOCK WASHER
36 Q230-036 CROSS RECESSED TRUSS HEAD SCREW
37 Q230-037 CROSS RECESSED TRUSS HEAD SCREW
38 Q230-038 BLADE GUARD LIFTING BLOCK
39 Q230-039 LENS HOLDING PLATE
40 Q230-040 GLASS
Original instructions
Qty. Ref. No.
1 82
1 83
1 84
1 85
1 86
2 87
2 88
2 89
1 90
3 91
1 92
1 93
1 94
1 95
1 96
1 97
1 98
1 99
1 100
3 101
3 102
1 103
2 104
4 105
1 106
1 107
1 108
1 109
1 110
1 111
1 112
1 113
1 114
1 115
1 116
1 117
1 118
1 118.1
1 119
17
Nov 2019
Part No. Description.
Q230-082 BALL BEARING
Q230-083 ARMATURE ASS'Y
Q230-084 BALL BEARING
Q230-085 PAN HD SELF-TAP SCREW/WASHER
Q230-086 FIELD ASS'Y
Q230-087 BRUSH HOLDER
Q230-088 BRUSH
Q230-089 BRUSH CAP
Q230-090 REINFORCE PLATE
Q230-091 SCREW PAN HEAD M5+WASHER
Q230-092 MOTOR HOUSING
Q230-093 GUIDE RULER
Q230-094 RIVET
Q230-095 WING SCREW
Q230-096 WASHER
Q230-097 BEVEL PLATE
Q230-098 CUTTING DEPTH SCALE PLATE
Q230-099 FLAT WASHER
Q230-100 HEX BAR
Q230-101 E-RING (ETW)
Q230-102 SECURE LEVER
Q230-103 FLAT WASHER
Q230-104 LOCK WASHER M5
Q230-105 SOCKET SCREW
Q230-106 WING SCREW
Q230-107 SPRING SHAFT LOCK BUTTON
Q230-108 SCREW
Q230-109 BASE PLATE
Q230-110 LOCK LEVER
Q230-111 FLAT WASHER
Q230-112 BEVEL LOCKING PLATE
Q230-113 MITER INDICATOR
Q230-114 CROSS RECESSED TRUSS HEAD SCREW
Q230-115 SET SCREW
Q230-116 NUT LOCKING
Q230-117 CARRIAGE SCREW
Q230-118 RACKET
Q230-118.1 BEVEL SCALE
Q230-119 FLAT HD SCREW
Qty.
1
1
1
2
1
2
2
2
4
1
1
1
3
1
1
1
1
1
1
1
1
1
1
1
2
2
2
1
1
1
1
1
1
1
1
1
1
1
2
