4)SPECIFICATION

Rated voltage
Rated input
No load speed
Arbor
Saw blade diameter
Arm-held vibration
Weight
Max. cutting depth at 90 ﾟ
Max. cutting depth at 45 ﾟ
Max. cutting thickness
Sound power level
Sound pressure level
Ear and eye defenders must be worn when operating this machine. Wear gloves to protect hands when operating the machine.
WARNING: THIS APPLIANCE MUST BE EARTHED!
NB: ANY MODIFICATIONS TO THIS MACHINE WILL INVALIDATE THE GUARANTEE
Original instructions
110-120V~ 50/60Hz 220-240V~ 50/60Hz
1800W
-1
2300min (RPM)
15.9mm
230mm(9"
)
6.75m/s2 k=1.5
9.5kg
83mm
56.5mm
6mm
12mm in section
95.5 dB(A)
93.8 dB(A)
Suitable only for a single phase 50-60Hz A.C. power supply
DO NOT USE ON D.C. SUPPLY
