Parts List - Rotabroach ELEMENT 14 Original Instructions Manual

Element 14 Manual

11) PARTS LIST

No. Part No. Description
1 PT0001 Screw M5x12
2 PT0002 Dust Filter
3 PT0003 Bearing Support Plate
4 PT0004 Washer
5 PT0005 Screw M5x10
6 PT0006 Contact Shield
7 PT0007 Label
8 PT0008 Cap Screw M5x15
9 PT0009 Depth Stop
10 PT0010 Motor Housing
11 PT0011 Label
12 PT0012 Washer
13 PT0013 Screw M5x10
14 PT0014 Left Handle
15 PT0015 Tapping Screw ST4.2X16
16 PT0016 Screw M5x50
17 PT0017 Screw M5x30
18 PT0018 Tapping Screw ST4.2X13
19 PT0019 Cable Clamp
20 PT0020 Cable Sheath
21 PT0021 Cable 110v
PT0022 Cable 230v
22 PT0023 Right Handle
23 PT0024 Trigger
24 PT0025 Nut M5
25 PT0026 Lower Handle
26 PT0027 Safety Switch
27 PT0028 Spring
28 PT0029 Upper Handle
29 PT0030 Tapping Screw ST4.2X13
30 PT0031 Switch
31 PT0032 Capacitor
32 PT0033 Rubber Ring
33 PT0034 Carbon Brush Holder
34 PT0035 Carbon Brush
35 PT0036 Carbon Brush Holder Cap
36 PT0037 Field Coil 110v
PT0038 Field Coil 230v
37 PT0039 Spring Washer M5
38 PT0040 Screw M5x80
39 PT0041 Air Buffle
40 PT0042 Bearing 6200
41 PT0043 Armature 110v
PT0044 Armature 230v
42 PT0045 Bearing 6202
43 PT0046 Gearbox Cover
44 PT0047 Key M5x12
45 PT0048 Spring
46 PT0049 Circlip
47 PT0050 Spindle Lock
48 PT0051 Bearing 6000
49 PT0052 Gear I
50 PT0053 Flat Key 5x12
51 PT0054 Shaft
52 PT0055 Bearing 6200
•
Applies to machines manufactured from August 2021 onwards
Original instructions
Qty No. Part No. Description
2 53 PT0056 Bearing 6201
1 54 PT0057 Gear II
1 55 PT0058 Flat Key 6x12
1 56 PT0059 Shaft(2)
2 57 PT0059 Bearing 6204
2 58 PT0060 Gear box
1 59 PT0061 Circlip
2 60 PT0062 Screw M4x12
1 61 PT0063 Warning Lable
1 62 PT0064 Plastic Cover
1 63 PT0065 Cap Screw M4x10
1 64 PT0066 Blade Housing
1 65 PT0067 Screw M5x90
1 66 PT0068 Rubber Ring
10 67 PT0069 Screw M5x12
2 68 PT0070 Screw M4x10
1 69 PT0071 Spring
2 70 PT0072 Screw M4x10
1 71 PT0073 Blade Guard(2)
1 72 PT0074 Circlip 42
1 73 PT0075 Inner Flange
1 74 PT0076 Screw
1 75 PT0077 Wheel
1 76 PT0078 Connecting Rod (1)
4 77 PT0079 Screw
1 78 PT0080 Connecting Rod (2)
1 79 PT0081 Screw
1 80 PT0082 Screw
1 81 PT0083 Blade Guard(3)
2 82 PT0084 Spring Washer 4
1 83 PT0085 Screw M4x10
1 84 PT0086 Label
1 85 PT0087 Blade Guard Cover
2 86 PT0088 Washer
2 87 PT0089 Screw
2 88 PT0090 Label
1 89 PT0091 Screw
1 90 PT0092 Blade
2 91 PT0093 Outer Flange
2 92 PT0094 Washer
1 93 PT0095 Spring Washer
1 94 PT0096 Cap Screw M10X30
1 95 PT0097 Screw M6X63
1 96 PT0098 Washer
1 97 PT0099 Plastic Handle
1 98 PT0100 Nut
2 99 PT0101 Wheel Handle
1 100 PT0102 Pin 4x25
1 101 PT0103 Screw Rod
1 102 PT0104 Vice Screw Support
1 103 PT0105 Washer
1 104 PT0106 Locking Nut M10
1 105 PT0107 Washer
1 106 PT0108 Connecting Rod
1 107 PT0109 Split Pin 3x26
17
Jan 2020
Qty No. Part No. Description
1 108 PT0110 Moving Vice Jaw
1 109 PT0111 Circlip 22
1 110 PT0112 V-vice
1 111 PT0114 Back Vice
1 112 PT0115 Ring
1 113 PT0116 Washer 10
1 114 PT0117 Spring washer 10
3 115 PT0118 Cap Screw M10x25
1 116 PT0119 Screw
1 117 PT0120 Angle Adjust Handle
2 118 PT0121 Spring
1 119 PT0122 Screw
4 120 PT0123 Angle Ruller
2 121 PT0124 Screw
1 122 PT0125 Cast Iron Plate
1 123 PT0126 Cap Screw M8X40
1 124 PT0127 Sprign Washer 8
1 125 PT0128 Washer 8
1 126 PT0129 Cap Screw M8X35
1 127 PT0130 Rubber Foot
1 128 PT0131 Swarf Tray
1 129 PT0132 Swarf Tray Cover
1 130 PT0133 Screw M4x10
1 131 PT0190 Base
2 132 PT0142 Wrench Holder
1 133 PT0143 Screw M5x15
1 134 PT0144 Rubber Ring
1 135 PT0145 Allen Wrench 8MM
1 136 PT0146 Cap Screw M8X25
4 137 PT0147 Spring washer 8
4 138 PT0148 Washer 8
1 139 PT0149 Lock
1 140 PT0150 Pin 3x18
1 141 PT0151 Lock Base
1 142 PT0152 Spring
1 143 PT0153 Lock Pin
1 144 PT0154 Circlip 24
1 145 PT0155 Pivot Pin
1 146 PT0156 Torsion spring
666677
1 147 PT0157 Nut M8
7766
1 148 PT0158 Screw M8 x 50
1 149 PT0159 Grub screw M5
1 150 PT0160 Washer M6
1 151 PT0161 Spring washer M6
1 152 PT0162 Cap screw M6 x 20
1 153 PT0163 Connecting plate
1 154 PT0164 Movable seat
1 155 PT0165 Pin
1
1
1
1
1
1
1
Qty
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
2
2
2
2
2
1
1
10
1
1
2
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
2
2
2
2
1
1
1
