Electronics Line Penta Installation Manual page 20

Address 07: Entry Delay Time
The entry delay timer determines the amount of time the user has to disarm the system
before an alarm is activated. The entry delay is only initiated if the premises are entered
through a zone defined as 'perimeter with delay'. Enter a hexadecimal value between 1 and
255 seconds at this address using the hexadecimal conversion chart in Appendix A.
Address 08: Exit Delay Time
The amount of time the user has to leave the premises after arming is determined by
the exit delay timer. An open zone will not activate an alarm during this period. Enter a
hexadecimal value between 1 and 255 seconds at this address using the hexadecimal
conversion chart in Appendix A.
Address 09: Bell Cut-Off Time
The bell cut-off is the period of time that the bell or siren will be activated after an alarm
has occurred. Enter a value between 1 and 5 minutes at this address.
Address 10: PGM Options
The PGM (Programmable Output) can be used for indication of certain status or trouble
conditions. When the PGM output is activated terminal 9 switches to ground. Choose
the PGM output setting from the following table.
Value Name
00 PGM Disabled
01 Arm/Disarm
02 Entry/Exit
04 Communication
08 AC Loss
10 Bell Follower
20 Duress
40 Alarm
80 Chime Follower
Event Codes
All events can be programmed to transmit a two digit event code message to the
central station. These codes are usually assigned by the central station - consult the
central station operator/owner for a listing of the different event codes. To disable an
event code program the code as 00.
Address 11: Alarm from Zone 1*
Address 12: Alarm from Zone 2*
Address 13: Alarm from Zone 3*
Address 14: Alarm from Zone 4*
Address 15: Alarm from Tamper Zone*
†
To deactivate the PGM output, the relevant log must be viewed.
*
When using the Follow-me feature, program these addresses with a value greater than 00.
Activated By
---
System Armed
Entry/Exit Tone Follower
System in Communication
AC Loss
Bell Follower
Duress Code
System in alarm
Keypad Chime Follower
-20-
Deactivated By
---
System Disarmed
Entry/Exit Tone Follower
End of Communication
AC Restore
Bell Follower
(deactivated after 2 seconds)
Arming/Disarming/View log
Keypad Chime Follower
†
