1
Product description
The Mastervolt EasyView 5 is a 4.3" touch display that allows the user to monitor, configure and
operate all connected devices in a MasterBus network.
Parts
1.1
Parts
1
Front cover*
2
Display panel
3
Top cover
4
Seal**
5
Wall box
6
Bottom cover
* Always use the front cover when the EasyView 5 display needs to be protected from damage or
sunlight.
** Always use the seal when the EasyView 5 display needs to be protected from water, moist and
dust.
EasyView 5 - User and Installation Manual
3
