Installation instructions
The EasyView 5 offers three mounting options:
Panel mounting onto the wall box
•
Flush mounting in an 82 x 113 mm hole
•
Clamp mounting in a hole > 82 x 113 mm - see section 4.2
•
Panel mounting
4.1
3mm
PH2
EasyView 5 - User and Installation Manual
- see section 4.1
- see separate instruction sheet with saw template
9
