4
EasyView 5 - User's and Installation Manual
1

Product description

The Mastervolt EasyView 5 is a 4.3" touch display that allows the user to monitor, configure and
operate all connected devices in a MasterBus network.

Specifications

1.1
Specifications
Model
Product code
Weight
Dimensions
Display size
Display languages
IP degree
Power supply
Power consumption
EasyView 5
77010310
0.36kg
0.79lbs
113 x 127 x 43 mm
4.4 x 5.0 x 1.7 in
109 mm
4.3 inch
EN/NL/DE/ES/IT/
FR/FI/SV/NO/DA
IP65 front
IP23 back
MasterBus /
12V/24V input
Sleep mode
~ 0.9W
Normal mode
~ 1.6W
