- Page 1 ThermalTronix TT-CXS-DVACS Thermal Camera Specifications User Manual...
- Page 2 Warranty If the product does not operate properly in normal conditions, please let us know. Intellisystem Technologies will resolve the problem for free of charge. The warranty period is 1 years. However, the followings are excluded: ...
- Page 3 Warnings Please avoid aiming the lens at extreme high temperature radiation source, such as the sun, molten steel or laser in any situation; otherwise the detector may be damaged. Please do not touch the lens to avoid contaminating and damaging. Please pay attention to protect the lens to avoid causing abrasion, scratches even breaches, otherwise, it will affect the device performance badly, even damage the device.
-
Page 4: Table Of Contents
Contents INTRODUCTION ..........................4 1.1 FEATURES ............................4 1.2 INCLUDED ............................5 2 COMPONENT NAMES AND FUNCTIONS ..................5 2.1 D ..........................5 EVICE APPEARANCE 2.2 C ........................6 ONNECTOR DEFINITION OPERATION GUIDE ........................6 3.1 C ......................6 OMMUNICATION PARAMETERS 3.2 O .......................... -
Page 5: Introduction
1 Introduction TT-CXS-DVACS is composed of uncooled infrared thermal imaging module and visible light camera, which can be applied in the following fields: long-range seaports, border, airport; middle-range power stations, public places; short-range gate of entry and exit, equipment storage sites;... -
Page 6: Included
1.2 INCLUDED TT-CXS-DVACS List for accessories and files： accessory quantity remark Pan-tilt AC24 Power Adapter User manual Packing list qualification 2 Component names and functions 2.1 Device appearance Fig. 1 Description Remark Thermal housing Thermal camera Rear cover CCD housing Include CCD camera and protocol board DIP switch cover definition refers to chapter 4.2... -
Page 7: Connector Definition
2.2 Connector definition The control wire is from bottom of PT system. Definition as follows: Description Remark RS485+ RS485 RS485- CCD Video Analog video output of CCD camera IR Video Analog video output of thermal imaging camera AC24V Power supply 3 OPERATION GUIDE 3.1 Communication parameters PELCO-D... -
Page 8: Operation Key Guide
3.2 Operation key guide 3.2.1 Thermal camera control key description Before operate thermal camera, please set address 2 firstly. Operational keys Function PTZ up Down PTZ down Left PTZ left Right PTZ right Enter the menu* or move the LENS- cursor from up to down LENS+ Manual calibration... -
Page 9: Thermal Imaging Camera Menu
3.3 Thermal imaging camera menu Before operate thermal camera, please set address 2 firstly. 3.3.1 Main menu Trigger『LENS-』to go to main menu, shown as Fig. 2： Fig.2 When the menu pops-up, trigger the 『LENS-』 to move the cursor , use 『FOCUS+』 and 『FOCUS-』 to modify the values or options. - Page 10 Note: when Auto 0 and 1, Mode X cannot be adjusted; when Auto 2, Mode X can be adjusted. G: XXX Gain value, range: 0-255 B: XXX Brightness value, range: -2048-+2048 P: XXX White/black hot display mode 0: black hot 1: white hot Z: XXX Zoom status...
- Page 11 communication parameters, please refer to 3.3.3. use『FOCUS+』and 『FOCUS-』to go to internal menu to setup mode 2、 Mode：XXX parameters, please refer to 3.3.4. 3、 AF: XXX Automatic focusing; 4、 RS: XXX Set the zeroing parameter 5、 Video: XXX Set the image quality 6、...
-
Page 12: Change Address
3.3.4 Mode menu In the system menu, move the cursor to “mode”, and use『FOCUS+』and 『FOCUS-』 to go to mode menu. You need to input password when go to system menu, the password is『FOCUS +』 『FOCUS-』 『LENS-』 『LENS+』 『FOCUS +』 『FOCUS-』 . With the correct password, you will come to the mode menu shown as Fig.5. -
Page 13: Change The Address Of Pt System
4.1 Change the address of PT system PT System address is minus 1 of thermal camera. Use a Phillips screwdriver to loosen four Phillips Screws on the DIP switch cover (refer to chapter 2.1), remove the DIP switch cover, you can see the circuit board DIP switch as shown in Fig.6. Fig. -
Page 14: Change The Address Of Visual Camera
4.3 Change the address of visual camera SAME WITH PT system address Open the housing. Check the SETUP in the rear of visual camera (Fig.7) Popup the menu of camera after pressing the SETUP about 2 seconds refer to Fig.8 Pressing 『SETUP』switch (up or down), you can move up or down on the menu to “COMMUNICATION”. -
Page 15: Change The Address Of Protocol Board
2.BaudRate Must be 9600; otherwise the Thermal imaging camera cannot be controlled. 3.ADDRESS Setup the camera’s address. and pressing 『SETUP』switch to exit the menu. Before exiting the Moving cursor to setup screen, select 『SAVE』 to save your settings. 4.4 Change the address of protocol board Same with the PT system address. - Page 16 Fig.11 Switch (Fig.11) from left to right is note as 1 2 3 4 bit. Up means off, down means on Address No.1 No.2 No.3 No.4 ..
-
Page 17: Troubleshooting
5 Troubleshooting Please follow the below table to diagnose and solve the problem. If problem is still exited, please contact our service center. Trouble Possible cause Solution Power wire connects wrong or After power-on, PTZ Again connect the power wire does not perform not well self-checking... -
Page 18: Technical Specifications
6 Technical specifications Items ThermalTronix TT-CXS-DVACS Detector characteristics Detector type Un-cooled FPA micro-bolometer Resolution 384*288 Detector pitch 25μm Image characteristics TT-1040CXS-DVACS f=40mm，F#=0.9 lens focus TT-1075CXS-DVACS f=75mm，F#=0.9 Spatial resolution 0.33mrad NETD ≤120mk@f/1,300k,50Hz Focus Auto focus according to scenery variety Thermal TT-1040CXS-DVACS 13.7º×10.3º...
