Intellisystem ThermalTronix TT-J Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ThermalTronix
1
TT-J Series
Thermal Camera Specifications
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ThermalTronix TT-J Series and is the answer not in the manual?

Questions and answers

Related Manuals for Intellisystem ThermalTronix TT-J Series

Summary of Contents for Intellisystem ThermalTronix TT-J Series

  • Page 1 ThermalTronix TT-J Series Thermal Camera Specifications User Manual...
  • Page 2 Intellisystem Technologies. Disclaimer Intellisystem Technologies makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user’s own responsibility. Intellisystem Technologies reserves the right to change the contents of this document without prior notice.
  • Page 3 OVERVIEW IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions Don’t focuses on the strong radiation source (Sun、Direction laser beam or reflection). Don’t use strong corrosive cleaner to clean the device. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
  • Page 4 CAUTION EXPLANATION OF GRAPHICAL SYMBOLS The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying...

  • Page 5: Web View

    Catalogue 1. OVERVIEW 1.1 Product features 1.2 Recommended PC specifications 1.3 At a glance 2. INSTALLATION & CONNECTION 2.1 Installation 2.2 Connect with other device 3. NETWORK CONNECTION AND SETUP 3.1 Connecting the camera directly to local area networking 3.2 Connecting the camera directly to a DHCP based DSL/Cable modem 3.3 Connecting the camera directly to a PPPoE Modem 3.4 Connecting the camera to a broadband router with the PPPoE/Cable modem 3.5 Search IP Interface...
  • Page 6 5. SETUP SCREEN 5.1 Setup 5.2 User Management 5.3 Network Setup 5.4 System setup 5.5 VIDEO & AUDIO setup 5.6 Storage management 5.7 Network Security 5.8 System maintenance 5.9 Log 6. ALARM CONFIRGURATION 6.1 Gray value alarm 6.2 Motion Detection 6.3 Video shield 6.4 Unusual alarm 6.5 Crossing alarm...

  • Page 7: Product Features

    1. OVERVIEW 1.1 Product features Pseudo-color You can select different color mode on camera, to display high or low temperature of object.  Multi-Streaming This network camera can display videos in different resolutions and qualities simultaneously using different CODECs.  Web Browser-based Monitoring Using the Internet web browser to display the image in a local network environment.
  • Page 8  ONVIF Compliance This product supports ONVIF profile-S。 For more information, refer to www.onvif.org. 1.2 Recommended PC specifications  CPU : Intel Core 2 Duo 2.4 GHz or higher (for using 1920x1080 30 fps) Intel Core i7 2.8 GHz or higher (for using 1920x1080 60 fps) ...
  • Page 9 WHAT’S INCLUDED Please check if your camera and accessories are all included in the product package. Appearance Item Name Quantity Description Camera User Manual PDF 12V power adapter RJ45 waterproof sleeve Protecting RJ45 network interface for water Screw spike For installing on ceiling and wall Warranty card 1.3 At a Glance...
  • Page 10 Appearance Item Description Fixed screw holes To install the camera on panel. installation Fixed screw for To adjust the monitoring direction. monitoring direction...
  • Page 11 Output line Item Description To connecting PoE or Ethernet cable. Network port To testing monitor output port. Using the testing monitor cable to Testing displayer connect the display to test the video. output Protective earth To protecting the product for lighting and surge. port To connecting loudspeaker Audio output hole...

  • Page 12: Installation And Connection

    2. Installation & Connection 2.1 Installation Precautions before installation Ensure you read out the following instructions before installing the camera:  It must be installed on the area (ceiling or wall) that can withstand 5 times the weight of the camera including the installation bracket. ...

  • Page 13: Ethernet Connection

    2.2 Connect with other device Ethernet connection Connect the Ethernet cable to LAN or Internet. Analog video output Connect the video output port to the video input port on monitor.  Video output∶ Single output signal lines (Max.1.0 Vpp)  Line out impedance∶75Ω...
  • Page 14 Power Cable Specification for Each Model In case of DC 12V Input: ＃22 ＃20 ＃18 Type（AWG） Cable Length （Max.） Network Cable Specifications Item Contents Remark Connector RJ45 Ethernet 10/100Base-T 10/100Mbps Cable UTP Category 5e Max. Distance 100m PoE Support IEEE802.3af Grounding the Product Connect the device housing to earth by using screwdriver.
  • Page 15 Recommended Grounding Cable  Length : Less than 3M  Gauge : 18 AWG or bigger Ex) UL1007 AWG 18/16, UL1015 AWG18/16/14/12, UL2468 AWG18/16/14  Connecting to Audio Input/Output 1. Connect the AUDIO IN port of the camera with the microphone or LINE OUT port of the amplifier that the microphone is connected to.
  • Page 16 Audio Codec - Audio In: G.711 PCM (Bit Rate: 64kbps / Sampling Frequency: 8kHz), G.726 - ADPCM (Bit Rate: 16Kbps, 24Kbps, 32Kbps, 40Kbps / Sampling Frequency: 8kHz) - Audio Out: G.711 PCM (Bit Rate: 64kbps / Sampling Frequency: 8kHz) Full duplex Audio ...

  • Page 17: Network Connection And Setup

    3. Network Connection And Setup You can set up the network settings according to your network configurations. Connecting the camera directly to local area networking Connecting to the camera from a local PC in the LAN 1. Launch an Internet browser on the local PC. 2.
  • Page 18 Connecting the camera directly to a DHCP based DSL/Cable modem 1. Connect the user PC directly with the network camera. 2. Run the IP Installer and change the IP address of the camera so that you can use the web browser on your desktop to connect to the Internet.
  • Page 19 Connecting the camera directly to a PPPoE Modem 1. Connect the user PC directly with the network camera. 2. Run Search IP Installer and change the IP address of the camera so that you can use the web browser on your desktop to connect to the Internet. 3.
  • Page 20 8. Restart the camera.  For registering the DDNS settings, refer to “Registering with DDNS”.  For configuring the DDNS settings, refer to “DDNS”. Refer to “IP & Port” for how to setup IP. Connecting the camera to a broadband router with the PPPoE/Cable modem This is for a small network environment such as homes, SOHO and ordinary shops.
  • Page 21 ex2) if the address (LAN IP) of the Broadband Router is 192.168.0.1 IP address: 192.168.0.100 Sub net Mask: 255.255.255.0 Default Gateway: 192.168.0.1 ex3) If the address (LAN IP) of the Broadband Router is 192.168.xxx.1 IP address: 192.168.xxx.100 Sub net Mask: 255.255.255.0 Default Gateway: 192.168.xxx.1 For the address of the Broadband Router, refer to the product’s documentation.
  • Page 22 Search IP Interface Item Description Display the process of searching Search…. Camera ID that connecting Device ID Camera model name that connecting Device Type The Ethernet address of camera that connecting IP address of connecting camera IP address The sub net mask of connecting camera Sub net mask The gateway of connecting camera Default gateway...
  • Page 23 Display the IP, sub net mask and gateway of camera for modification Modify the IP, sub net mask and gateway of camera Change Reset the camera to factory defaults Restore For Search IP, please use the version installed on the CD or the latest version. Static IP setup Run<Search IP V1.00>...
  • Page 24 3. Select a camera from searching list, <Device ID>、<IP address>、<Sub net mask>、 <Default gateway> of camera will displayed below.  MAC: The MAC address of camera is automatically displayed and requires no user setting. If not using a Broadband Router For setting <IP Address>、<...
  • Page 25  The settings may differ depending on the connected Broadband Router model.  For more information, refer to the user manual of the applicable router. If the Broadband Router has more than one camera connected. Configure the IP related settings and the Port related settings distinctly with each other. Category Camera#1 Camera#2...

  • Page 26: Web Viewer

    Connecting to the camera from a sharped local PC . Run Search IP. It will scan for connected cameras and display them as a list. 2. Access to the camera can also be gained by typing the camera's IP address in the address bar of the Internet browser.
  • Page 27 Using URL 1. Launch the Internet browser. 2. Type the DDNS URL of the camera in the address bar. ex) URL address : ddns.hanwha-security.com/User name - The Login dialog should appear.  Network connection is disabled in the LAN only environment. To check the DDNS address If the camera is connected directly to the DHCP cable modem, DSL modem, or PPPoE modem, the IP address of your network will be changed each time you try to connect to the ISP...

  • Page 28: Password Setting

    Password setting 1. When you access the product for the first time, the login gorge will pop-up. 2. Input user name “admin”. 3. Click [confirm] to into “password change” window. 4. Input new password on “password change” window.  For a new password with 8 to 9 digits, you must use at least 3 of the following: uppercase/lowercase letters, numbers and special characters.
  • Page 29  Can not use repeat 4 character，ex：????,1111, aaaa. Log in Whenever you access the camera, the login window appears. Enter the User ID and password to access the camera. 1. Enter “admin” in the <User name>input box. 2. Enter password in the <Password> input box. 3.
  • Page 30 Installing VLC setup plugin If connecting to a camera for the first time, you will see the installation message. Then, install the required VLC media player Plugin to access the camera and control the video from it in real time. 1.
  • Page 31 4. Click [Next] to install the Plugin. Using the live screen...
  • Page 32 Items Description Move to the monitoring screen. Live View Move to the screen where you can search for the video recording saved Playback in your Micro SD memory card or NAS. Move to the Setup screen. Setup Move to alarm setup screen Alarm Display current user Admin...
  • Page 33 connecting Web Viewer. Selecting different color mode to distinguish high & low temperature Pseudo- of the object. color Revise the thermal image manually when the image lag appeared. Manual zero setting Select different Auto zero setting modes. Manual  When selecting “short”, zero setting every 1 minute. correction ...
  • Page 34  vertical Flip vertical off, display the original image. Select if flip the image horizontally. Flip  Flip horizontal on, the image will be mirror left-right. horizontal  Flip horizontal off, display the original image. Enable or disable the voice output. Voice output Full screen...
  • Page 35 Item Description Set the search date and time range for data saved in your Start time Micro SD memory card or NAS. End time Configure the event type you want search. Recording type Select the source of events. Source SD：Search the event from SD card NAS：Search the event from NAS server Run event searching Search...
  • Page 36 Paging of searching list. Paging Display the data searched. Searching list Play video 1. Click [ ] Button 2. Specify the start time and end time of your search. 3. Select an event type and source for your search within the specified period. 4.
  • Page 37 6. When playing the video, the section in the specific period is played by moving the time bar. 7. To listen to a voice signal in the recorded video, then activate the voice signal icon [ when you play it. If the voice signal icon is [ ], it’s silent mode.
  • Page 38 To Play an AVI File on Micro SD memory card 1. Take out the Micro SD card from the camera. Before separating the Micro SD memory card, set the <Open the recording plan> to <Off> in the “<Setup>→<storage management>→<recording plan>” menu.

  • Page 39: Setup Screen

     YYYYMMDDHHMMSS means starting time of saved data.  Each AVI file’s size is Max. 512M.  If you change or damage the saved data on your own, it will not play back or save properly. 5. Setup screen 5.1 Setup On the network, you can set up basic information on the camera, video and audio, network events and system.

  • Page 40: User Management

    1. In the Live screen, click [ 2. The Setup screen appears. 5.2 User Management 1. From the setup menu, select the <User>tab. 2. Provide the necessary user information • Administrator password change∶ Change the password for the administrator  For the security purposes, you are recommended to use a combination of numbers, alphabets uppercase and lowercase and special characters for your password.
  • Page 41 - A combination of at least two types of upper case, lower case, numeric, and special characters: 10 to 15 characters. - Should be different from the ID. - For higher security, you are not recommended to repeat the same characters or consecutive keyboard inputs for your passwords.

  • Page 42: Network Setup

    5.3 Network Setup TCP/IP 1. From the Setup menu, select the<Network setup> tab. 2. Click<TCP/IP>。 3. Set<IPv4 setup>。 • IP Type∶ select IP type - Manual∶ Specify the IP address, Sub net mask, Gateway, DNS1 and DNS2. - DHCP∶ Specify the DNS1 andDNS2. If you set it to <Manual>, you should specify the IP, Sub net mask, Gateway, DNS 1 &...
  • Page 43 • IP Address∶ Displays the current IP address. •Sub net Mask∶ Displays the <Sub net mask> for the set IP. •Gateway∶ Displays the <Gateway> for the set IP. • DNS1/DNS2∶Displays the DNS (Domain Name Service) server address. 4. Set the <IPv6 setup>. •...
  • Page 44 Setting the HTTP port for Google Chrome browsers to 65535 is not allowed by security policy. HTTP port can not modify into 8000、5000 and 8080。 • HTTPS∶ In this version, the security of the web communication protocol HTTP is strengthened. It can be used when you set HTTPS mode in SSL.
  • Page 45 DDNS DDNS is an abbreviation of Dynamic Domain Name Service that converts the IP address of a camera into a general Host Name so that the user can easily remember it.  You can use the DDNS service only if the internet is connected. 1.
  • Page 46 5. Click <apply> to finish. Register your product on ddns.hanwha-security.com Visit ddns website (ddns.hanwha-security.com) and login by using the registered user 2. Select <MY DDNS> after login 3. Click [Register Product] to register your product. 4. Input product ID. You must rechecking the ID you input.
  • Page 47 5. Select<Type> and <MODEL >. 6. Specified product position and description (if need). 7. Click [Product Registration]. The product will added on product list, you can check it.
  • Page 48 PPPoE The camera will get a public network IP.  You only can use PPPoE service by connecting internet. 1. Select <network setup> from configuration menu. 2. Click <PPPoE>. 3. Open <PPPoE>, input PPPoE user name and password 4. Click <yes> to finish. You can configure the FTP server settings so that you can transfer the image taken with camera to your PC if an event occurs.
  • Page 49 2. Click <FTP>. 3. Open <FTP>，and input the information you need. • FTP Configuration - Server address∶ Enter the IP address of the FTP server that you transfer the alarm or event images. Port∶ The default port of the FTP server is 21: however, you can use a different port number according to the FTP server settings.
  • Page 50 HTTPS Used for safe connecting system or installing public certification. From setup menu, select <network setup>tab. 2. Click<HTTPS>. 3. Open<HTTPS>. You must enter the camera’s IP address with https://<Camera_IP> format, if you want visit the camera by using HTTPS mode. 4.
  • Page 51 1. From the Setup menu, select the<Network setup> tab. 2. Click<Email>。 3. Open<Email>, input the value you need. - Server address∶ Enter the IP address of the email server that you transfer the alarm or event images to. - Port∶ The default port of the email server is 25; however, you can use a different port number according to the email server settings.
  • Page 52 802.1X When connecting network, you can choose whether using 802.1x protocol. 1. From the Setup menu, select the<Network Setup> tab. 2. Click <802.1x>. 3. Open<802.1x > to set homologous para. •EAP Type∶ Specify the use of the802.1x protocol. • EAP version∶ Select version 1 or 2. •User name∶...

  • Page 53: System Setup

    5.4 System setup Time setup 1. From the Setup menu, select the <System setup>tab. 2. Click<Time setup>。 3. Specify the time and date that will be applied to the camera. •Timezone∶ Specify the local timezone based on the GMT. •System time setup∶ Specify the time and date that will be applied to your system. - Manual∶...
  • Page 54 System para. 1. From setup menu, select <system setup>tab. 2. Click <system para.>. 3. Setting analog video output display mode. •System∶ Select analog video output mode. - PAL∶ Select PAL mode when local monitor is PAL. - NTSC∶ Select NTSC mode when local monitor is NTSC. 4.
  • Page 55 - Mode∶ camera name. - Software version∶ The current software version. - Hardware version∶ The current hardware version of camera. - Storage device∶ Local storage device that camera supported. - User amount∶ The current connected rear-end user amount. VIDEO & AUDIO setup Video setup 1.
  • Page 56 - Custom name∶ Display the custom camera name on the screen specified. - Movable camera name, time and custom name∶ If you want move someone OSD position, move cursor on homologous OSD, when the cursor display [ ], then hold left mouse button and move the cursor on new position.
  • Page 57 Due to rate will adjust limited according to resolution, rate and screen, the practical rate will bigger than Max.rate. So you should consider the environment when you set the value. -Frame rate: setting Max.frame quantity every second. 4. When done, click [yes]. Main code stream application 1.
  • Page 58 Audio para.setup. You can configure the audio codec settings of the audio source from the camera. 1. From the Setup menu, select the<Video & Audio > tab. 2. Click <Audio setup>. 3. Set the audio input value. • Source: Sets the audio input. - Line: Connect the cable to the audio device.

  • Page 59: Storage Management

    - G.711: A audio codec standard, it uses 64 Kbps PCM (Pulse Code Modulation) encoding. ITU standard audio codec that is adequate for digital voice transfer in PSTN network or through a PBX. - G.726: ITU standard audio codec applying ADPCM (Adaptive Differential Pulse Code Modulation) for variable bit rates of 40/32/24/16 Kbps to 64 Kbps PCM encoding.
  • Page 60 2. Click <recording plan> 3. Open <recording plan> 4. Drag the mouse, you can choose the time period, when the mouse drag, hold down the 'shift' or 'Ctrl' button, you can choose the time periods. 5. When done, click [yes]. If plan recording overlaps alarm recording, the device will only open alarm recording.
  • Page 61  It will display “Recording” when the device is recording data.  It will display “Ready” if turn “enable” to ”off”.  If display “ERROR”, please check below items: - Check memorizer, make sure it connects with device. - Check the file in the memorizer, make sure it didn’t damaged. - Check memorizer, make sure it didn’t been broken.
  • Page 62 NAS setting 1. Select<Storage management>tab. 2. Click<NAS Setup>. 3. Enter the information registered in your NAS.  IP Address：Unique IP address assigned to the NAS.  ID：An ID registered in the NAS.  Password: Password registered in the NAS.  Saving list: The NAS user file to save data.
  • Page 63 - Confirm that the ID/password of the NAS is valid. -Confirm that you can access the folder designated as the default folder using the ID of the NAS. -Confirm that the NAS IP address and the camera IP address are in the same format. ex) The NAS &...

  • Page 64: Network Security

    5.7 Network security IP address filtration Set up awarding or refusing visiting IP list. 1. From setup menu, select <network security>tab. 2. Click <IP address filtration>. 3. Open<security management>, select <default strategy>. •Refusing: if select this tab, it will award other IP to visit except the IP in filtration list. •Awarding: if select the tab, other IP cannot visit except the IP in the filtration list.

  • Page 65: System Maintenance

    5. When done, click [yes]. 5.8 System maintenance 1. From setup menu, select <System maintenance> tab. 2. Select the item you need to set. •Restart: restart the system. •Factory default: to reset the system into factory default.  The IP address won’t recover. ...
  • Page 66 5.9 Log You can check the system log or event log. 1. From the Setup menu, select the<log> tab. 2. Select log type. •Alarm log: check event log, include time information. •Unusual log: check unusual log, include time information. •Operation log: check operation log, include time information. •All: check system log, alarm log and unusual log.
  • Page 67 3. If one page cannot display all logs, please use page turning button. 4. Click < download> button to download the log data you selected.  Each page displays 12 logs with the latest one displayed at the top  The event/system log list can contain up to 5000 logs;...

  • Page 68: Alarm Configuration

    6. Alarm configuration Open timing recording and alarm recording at same time, the device will only record alarm recording. 6.1 Gray value alarm If gray difference value in the area greater than the threshold, it will alarm. 1. From alarm menu, select <gray value>tab. 2.
  • Page 69 4. Setup/selecting alarm condition. •Right-hand of detection area display Max.gray value of screen, average gray value, difference value and max.value of yellow area. • Threshold: When the threshold you set less than gray difference value, it will alarm. • Sensitivity: it will easy to alarm if the sensitivity value is high. 5.

  • Page 70: Motion Detection

    6.2 Motion Detection It detects a motion that meets all conditions specified by sensitivity, size and area. 1. From alarm menu, select <motion detection>tab. 2. Open <motion detection>. 3. You can appoint the area of screen to add on the detection area or evacuant area. •Detection area﹕By dragging with the mouse, you can select regions need to detect, drag the mouse and hold shift or Ctrl key select multiple regions, highlight areas for selected effective regional.
  • Page 71 'shift' or 'Ctrl' button, you can choose the time periods 5. It will run operation when appointed alarm triggering. About <alarm linkage>, please refer “gray value”. 6. Setting pre-recording: Appoint the time before alarm triggering; start at this time, it will save image.
  • Page 72 6.3 Video shield You can set when the lens is shielded, trigger alarm. 1. From setup menu, select <video shield>tab. 2. Open <video shield>. 3. Setting video shield sensitivity. Higher sensitivity, faster to detect video shield. 4. It will run operation when appointed alarm triggering. About <alarm linkage>and<pre- recording>, please refer “gray value”.
  • Page 73 6.4 Unusual alarm Disconnect network, IP conflicting, memorizer full and memorizer error will regard as unusual event. 1. From setup menu, select <unusual alarm>tab. 2. Select alarm type. •Network disconnection: you can select video recording when it detect network disconnecting. •IP conflicting: you can select video recording when it detects IP conflicting。...
  • Page 74 6.5 Crossing alarm It detects event that meets all conditions specified by sensitivity and area and the event condition rules. 1. From setup menu, select <crossing alarm>tab. 2. The device support 4 kinds crossing alarm modes. 3. Open <crossing alarm>. 4.
  • Page 75 5. About <arming time>, <alarm linkage>and<pre-recording>, please refer “gray value”. 6. When done, click [yes]. 7. If you want to delete the trip line you defined, please click [deleting trip line] button below. The size of target detected may be different with actual size, it’s depend on the shape.

  • Page 76: Area Alarm

    6.6 Area alarm It detects event that meets all conditions specified by sensitivity and area and the event condition rules. 1. From setup menu, select<area alarm>. 2. The device support 4 kinds area alarm modes. 3. Open <area alarm>. 4. Click 4 peaks to defined detection area on screen, then select the rules you need: •...

  • Page 77: Specifications

    7. Appendix 7.1 Specifications ThermalTronix Items TT-384J TT-640J Uncooled FPA micro bolometer Detector Resolution 384(H) X 288(V) 640(H) X 480(V) Pitch size 25μm 17μm Video Wave range 8-14μm Frame Frequency 50Hz Video output CVBS : 1.0 Vp-p / 75Ωrecombination，720x480(N)， 720x576(P)， 16.8°...
  • Page 78 Audio input Off/on Alarm Gray value, motion detection, video shield, area invading, crossing alarm, network disconnecting, IP conflicting, memorizer full, memorizer error.  Event alarm Upload to FTP.  Transfer to email  Saving in local device or recording on NAS when alarm trigger.
  • Page 79 -Support recording on NAS server. Application codec ONVIF Profile S port. Web Viewer Support : Microsoft Internet Explorer (Ver.9~11), Google Chrome (Ver.40 or under) Working -40°C ~ +60°C (+14°F ~ +131°F) / less than 90% RH temperature/humi dity Storage -45°C ~ +65°C (-22°F ~ +140°F) / Less than 90% RH temperature/humi dity Environment...

  • Page 80: Product Image

    7.2 Product image...
  • Page 81 7.3 Malfunction Removal Problem Solution  Check to make sure that the camera’s Network settings are appropriate.  Check to make sure that all network cables have been connected properly. I cannot access the camera  If connected using DHCP, verify that the camera is from a web browser able to acquire dynamic IP addresses without any problem.
  • Page 82 Check<hard disk> in <storage Cannot recording on Micro management>→<memorizer management>, if it displays SD card If plan recording time overlap with alarm recording time, Cannot record plan recording. the device will only record alarm recording. Open a lot kinds of alarm If open a lot kinds of alarm recording, the device will recording, only one alarm only record alarm recording.
