- Page 1 ThermalTronix TT-G2F-HTI TT-T2F-HTI Series Fire-fighting Thermal Image Camera User Manual...
- Page 2 Warning & Attention Warnings Under the environment of darkness and smoke, firemen can make the more accurate judgement and behavior more efficiently according to the TT-2F-HTI series thermal image camera. User must read the below statement very carefully, otherwise it may lead serious injury or even death. ...
- Page 3 When the device is exposed long time under the high temperature environment, it may lead device performance decreased or image lost. It must avoid over sensitization and temperature out of the designed range, otherwise it will lead heat saturation. If so, please move the device away from the high temperature environment to return normal image, otherwise the device may be damaged.
-
Page 4: Table Of Contents
Content Warning & Attention ......................1 Introduction ........................1 Standard accessories....................1 Overview .........................2 Getting started.........................3 Inserting battery ......................3 Remove battery ......................5 Notes on safety use battery ..................7 Operation guide .......................8 Interface description ....................8 Operation description ....................10 4.2.1 TT-2F-HTI operation flow chart ................ 10 4.2.2 TT-2F-HTI operation flow chart ................ -
Page 6: Warning & Attention
TT-2F-HTI series adopt advanced un-cooled FPA infrared detector and advanced real-time infrared thermal image process circuit with high definition and sensitivity which designed by Intellisystem Technologies. TT-2F-HTI series are hand-held conforming the ergonomics, where user can control it by single hand. -
Page 7: Overview
2. Overview Figure.2.1 Overview of TT-2F-HTI series Description Comment Long press to power on/off ① Power key the camera. Short press to change the color platter. ② Battery slot buckle ③ Knob/battery slot ④ Lens Germanium window ⑤ LCD screen Note: Practical device may not have the symbol (IR-TECH) on the appearance. -
Page 8: Getting Started
3. Getting started 3.1 Inserting battery Pull up the buckle of battery slot Pull up the buckle of battery slot Open the cover of the battery slot Open the cover of the battery slot... - Page 9 Push the battery into the battery slot Push the battery into the battery slot Close the battery slot cover Close the battery slot cover Push down the buckle of the battery slot Push down the buckle of the battery slot Note: only standard accessory battery is allowed to use, otherwise the battery may be stuck or wrong voltage will damage device.
-
Page 10: Remove Battery
3.2 Remove battery Pull up the buckle of battery slot Pull up the buckle of battery slot Open the cover of the battery slot Open the cover of the battery slot... - Page 11 Remove the battery from the battery slot Remove the battery from the battery slot Close the battery slot cover Close the battery slot cover Push down the buckle of the battery slot Push down the buckle of the battery slot...
-
Page 12: Notes On Safety Use Battery
3.3 Notes on safety use battery Battery should be stored among the environment temperature -20℃∽20℃. Since the battery will self discharge during storage, the battery should be charged fully before storing in order to avoid over discharge, which will impact the battery capacity. Furthermore, it is recommended that the battery should be charged in a set time, as below: ... -
Page 13: Operation Guide
4. Operation guide 4.1 Interface description [1] High temperature palette symbol: Displayed when system switch to high temperature palette automatically. [2] Spot temperature measurement: display the temperature of the object by spot temperature measurement. Note: Not supported by TT-2F-HTI. [3] Palette: Currently user choose pseudo colorful palette. There are four options: rainbow, black-hot, white-hot and fire-fighting. - Page 14 When working time of the battery is less than 20 minutes, the battery symbol will flash wholly in order to warn the operator. When working time of the battery is less than 2 minutes, it will flash “Battery exhausted” in the middle of the screen. After flashing 10 times, the system will power off with the prompt box “Starting power manage”.
-
Page 15: Operation Description
4.2 Operation description 4.2.1 TT-2F-HTI operation flow chart Power on Long press power New target Screen display the Palette change interface New target Aim at the new Short press target object power key Change palette New target New target target Aim at the new target thermal image... -
Page 16: Tt-2F-Hti Operation Flow Chart
4.2.2 TT-2F-HTI operation flow chart Power on Long press power New target Screen display the Palette change interface New target Aim at the new Short press target object power key Change palette New target New target Target temperature Aim at the new Target temperature target object displayed on the... -
Page 17: Technical Specifications
5. Technical specifications ThermalTronix Item TT-T2F-HTI TT-G2F-HTI Type Un-cooled FPA detector Resolution 160×120 384x288 Detector Range of λ performance 8～14μm ≤0.12℃@30℃ Thermal sensitivity Frame frequency 50Hz Image Colorful high resolution 3.5” LCD performance 30°×22.5° 40°x30.5° Lens parameters Spatial resolution 3.3mrad 2.18mrad Measurement range -20℃～+600℃... -
Page 18: Troubleshooting
6. Troubleshooting Please follow the below table to diagnose and solve the problem. If problem is still existed, please contact our service department. Problem Cause & Solution Battery not installed or installed incorrectly →Install battery or re-install battery Battery is out of power.
