- Page 1 ThermalTronix TT-1100B-UTCM Thermal Imaging Module User Manual...
- Page 2 Please read this User’s Manual before using the module！ Warnings Avoid aiming the window (with lens or not) at extreme high temperature radiation source (such as the sun, molten steel and laser) in any case (power on/off), or the detector may be damaged. Do not contact the detector window with bare skin in order to avoid contaminating and damaging it owing to static.
-
Page 3: Table Of Contents
CONTENTS INTRODUCTION ......................1 FUNCTIONS ........................1 MAIN TECHNICAL SPECIFICATIONS ................. 1 Detector ....................... 1 Module ........................ 1 INTERFACE ........................2 OPERATION GUIDE ......................2 Operation process ....................2 Control Key function explanations ................ 3 4 CONTROL KEY CHART......................4 5 OPERATING INTERFACE ...................... -
Page 4: Introduction
1. Introduction TT-1100B-UTCM Thermal Imaging Camera is specially developed for long range surveillance purpose especially under different environment situation. 2. Functions 1. Image Noise Reduction function, reduce Image background noise. 2. Image enhancing function: enhance the ability to detect small object 3. -
Page 5: Interface
4. Interface Pin definition of cable output Definition Description Remarks DC12V Input Power+ Power Ground KEY5（F） Crosshair setting key KEY3（C） Single calibration key VIDEO1 Video Output 1 Lower level trigger Video Ground Lower level trigger KEY4（M） Menu Key KEY1（+） UP Key KEY2（-）... -
Page 6: Control Key Function Explanations
Control Key function explanations ＋ KEY1 （+） － KEY2 （－） KEY3 （C） KEY4 （M） KEY5 （F） KEY1 (+): When the menu system is active, adjust the selected item parameter. Press the key to increase the parameter value. When the menu system is not active, press the key to focus forwards. -
Page 7: Control Key Chart
4 control key chart If with RS485, thermal camera address is 1, baud :9600, PELCO_D, details refer to 5.3. Control key in rear camera: Iris close (M key): without Menu, Press M key into MENU ；Press M key to 1） choose items in Menu。Change the value of choose with 『-』... -
Page 8: Operating Interface
5 OPERATING INTERFACE 5.1 Main menu Trigger『Aperture- off』to go to main menu, shown as Fig. 6： Fig. 6 When the menu pops-up , trigger the 『Aperture- off』 to move the cursor , use 『near focus』 and 『far focus』to modify the values or options. When you exit the menu, parameters automatically are saved. -
Page 9: System Menu
4、 B： XXXX Brightness value, range: -2048-+2048. This function is only effective when the auto imaging mode setup is Auto 0. In Auto 1 or Auto 2 modes, brightness is automatically adjusted. When trigger 『 Aperture- off』 , cursor will skip brightness setup option. - Page 10 1、 Com：XXX Please do not change the items within this menu, or the thermal camera may not be normally controlled. use 『near focus』 and 『far focus』 to go to internal menu to setup mode 2、 Mode： XXX parameters, please refer to 4.4. 3、...
-
Page 11: Menu Of Communication Protocol
5.45.3 Menu of communication protocol In menu，move to “Com” ，press『near focus』or『far focus 』in to menu of communication protocol. Then input the passport： 『 Iris open』 『 far focus』 『 Iris open』 『 near focus』 『 iris open』 『 iris open 』 。 As show in the picture 9。... - Page 12 will come to the mode menu shown as Fig. 8. Fig. 8 Trigger 『Aperture- off』and move the cursor, use『near focus』and 『far focus』to modify the values or options. 1、 Mode：X display the current mode No. 2、 Gain：XXX Gain value, range: 0~255; 3、...
