Fleck 7000 Sediment Filter Installation & Startup Guide
24. The next cycle is the Rinse cycle and this also runs for 10 minutes.
25. After the Sediment Filter has gone through the backwash and rinse, press the Extra Cycle button and
repeat the backwash and rinse. This is the same procedure that needs to be done each time you add
Sediment media in the future, that is, the Sediment media must be thoroughly backwashed and
rinsed.
26. Refer to your Fleck 7000 service manual for more information about how your control valve is
programmed if desired.

Fleck 7000 Metered Flow Sensor Filter System Programming Guide

This is for Fleck 7000 backwash filters that have are equipped with the optional built-in flow sensor only.
two types of programming, standard USER PROGRAMMING, where you can set the time of day and gallons of
water used and/or days between backwashes. The second type is MASTER PROGRAMMING where you can
set the length of the backwash and rinse cycles, and make sure the control is set to the correct settings for
your type of Sediment filter:

User Programming

You can go into User Programming and make adjustments if you want to the flow meter setting or Day
Override setting. Use the User Programming to avoid having to go through the Master Programming for quick
changes to these settings below:
1. Press the Up and Down buttons for five seconds while in service, and the time of day is NOT set to
12:01 PM.
2. Day Override (Display Code DO): Set to 1 to 14 based on your particular filter system requirements.
Use the Up or Down arrows to change the setting. This is the critical setting that allows your filter to
backwash every fixed number of days. See your Installation and Start-up Guide for more information
or contact us for suggestions for this setting. Press the Extra Cycle button.
3. Regeneration Time (Display Code RT): Set to 2:00 am generally or sometime when no water is being
used, and no other filter or softener is likely to be in a regeneration cycle. Press the Extra Cycle
button.
4. Feed Water Hardness: Use this setting to adjust the feed water hardness. Set for 20 for most
applications. Press the Extra Cycle button. Note that actual 'Feed Water Hardness" is irrelevant to
filter systems, since no hardness is being removed.
Page 12 www.cleanwaterstore.com
There are
Rev 051414
