3. HARDWARE DEVELOPMENT
48.2 mm
27.9 mm
18
mm
54.4 mm
Figure 25: Front Side of ESP32-DevKitC
3.8 ESP-WROVER-KIT Development Board
The ESP-WROVER-KIT is another development board built around ESP32. This board is compatible with ESP32
modules, including the ESP-WROOM-32 and ESP32-WROVER. The ESP-WROVER-KIT features support for an
LCD and MicroSD card. The I/O pins have been broken out from the ESP32 module for easy extension. The board
carries an advanced multi-protocol USB bridge (the FTDI FT2232HL), enabling developers to use JTAG directly
to debug ESP32 through the USB interface. The development board makes secondary development easy and
cost-effective.
The board's layout is shown in Figure
26
and Figure 27.
Figure 26: Front Side of the ESP-WROVER-KIT Layout
Espressif Systems
27
ESP32 Hardware Design Guidelines V2.1
