- Page 1 CLASSIC-LINE / ECO-LINE INSTRUCTION MANUAL...
-
Page 3: Table Of Contents
CLASSIC-LINE ECO-LINE Instruction manual CONTENTS INTRODUCTION INSTALLATION INSTRUCTIONS PICTOGRAMMES ABBREVIATIONS / TERMINOLOGY OPERATING SAFETY RULES SAFETY DISTANCE FUEL MAXIMUM WOOD LOADS DESCRIPTION OF A CONVECTION FIREPLACE (S FIREPLACE) DESCRIPTION OF A HEAT STORAGE AND RADIATION FIREPLACE (K FIREPLACE) ADJUSTMENT AND REGULATION... -
Page 4: Introduction
Read these instructions carefully and do not hesitate to ask your dealer if you have any questions. The explanantions in this manual are valid for all products of the Rüegg Classic-Line. For a more easy explanation, remarks that are valid for all fireplaces at the same time are summarized and explained on a certain model that may very well be different from yours. -
Page 5: Abbreviations / Terminology
CLASSIC-LINE ECO-LINE Instruction manual Abbreviations / Terminology Airwash Air-flow system to prevent soot build-up on the ceramic glass. AIR-Direct Independent combustion air supply Modèle A1 Fireplace with automatically-closing doors Combustion air Convection air BImSchV Bundes-Immissionschutzverordnung (federal law for preventing harm to the environment) (D) -
Page 6: Safety Distance
CLASSIC-LINE ECO-LINE Instruction manual Safety distance Space in front of the fireplace For solid-fuel fireplaces, a floor plate or fireproof flooring must be placed in front of the door and extend outwards by at least 40 cm. The plate should extend widthways at least 40 cm from either end of the fireplace door. -
Page 7: Fuel
CLASSIC-LINE ECO-LINE Instruction manual Fuel Use only good quality fuel if you want to get the best out of your fireplace. Use untreated logs with 20% maximum residual moisture. For maximum heating efficiency (1 kg ≈ 4.5 kWh), the wood should be stored in a dry area for at least 2 months. -
Page 8: Description Of A Convection Fireplace (S Fireplace)
CLASSIC-LINE ECO-LINE Instruction manual Description of a convection fireplace (S fireplace) 1 Flue gas exhaust outlet 2 Hot air outlet 3 Door fairing 4 Airwash system (for cleaning the glass) 5 Door locking latch 6 Fireplace door (retractable, sliding) 7 Combustion air supply... -
Page 9: Description Of A Heat Storage And Radiation Fireplace (K Fireplace)
CLASSIC-LINE ECO-LINE Instruction manual Description of a heat storage and radiation fireplace (K fireplace) Smoke exhaust outlet Nameplate Door fairing Airwash system (for cleaning the glass) Door locking latch Fireplace door (retractable, sliding) Combustion air supply Fireplace (firebrick or steel, without cast-iron grate,... -
Page 10: Adjustment And Regulation
CLASSIC-LINE ECO-LINE Instruction manual Adjustment and regulation Convection system (S / V fireplace): Fresh-air regulator (external convection air) Fresh-air regulator (AIR-Direct; external combustion air) Combustion-air intake control Smoke regulator control button Ambiant convection air intake vent 6/7 Hot convection air outlet vent... -
Page 11: Convection Air System Operation (V/S Fireplaces)
CLASSIC-LINE ECO-LINE Instruction manual Convection air system operation (S / V fireplaces) In convection air systems, part of the heat produced by combustion is blown into the room by the air flow moving through the convection jacket, the ducts and the convection-air grates. -
Page 12: Using Your Fireplace For The First Time
CLASSIC-LINE ECO-LINE Instruction manual Using your fireplace for the first time Remove all the documents and accessories from the fireplace. Read these instructions carefully before using the fireplace for the first time. Complete the warranty certificate and send it in to Rüegg. -
Page 13: Ignition
CLASSIC-LINE ECO-LINE Instruction manual Ignition 1 OPEN the convection air regulator* completely *if the system is fitted with one → Pull out the control OPEN the combustion air regulator* completely *if the system is fitted with one → Pull out the control 3 OPEN the air inlet control completely →... -
Page 14: Heating
CLASSIC-LINE ECO-LINE Instruction manual Heating About 15 minutes after loading the logs: 1 PARTIALLY CLOSE the convection air regulator* * if the system is fitted with one → Push the control half in 2 Combustion air damper* completely OPEN * if the system is fitted with one →... -
Page 15: Keeping The Fire Alight
CLASSIC-LINE ECO-LINE Instruction manual Keeping the fire alight Use the protective glove provided in the user kit, as the fireplace door and the ceramic glass sheet can get very hot! OPEN the smoke regulator completely* * if the system is fitted with one... -
Page 16: Open Fire/Grilling
CLASSIC-LINE ECO-LINE Instruction manual Open fire / grilling This is only allowed if the fireplace is not fitted with an automatically-closing door (model A1). To prevent smoke spreading into the room, you should switch off any devices liable to cause a depression, such as hoods and other fan-operated systems. -
Page 17: Keeping The Embers Going
CLASSIC-LINE ECO-LINE Instruction manual Keeping the embers going Before applying the guidelines for keeping the embers going, check that there are no flames or unburned wood in the hearth. Failing to check this or closing the combustion air supply too soon could result in deflagration (= explosive... -
Page 18: Shutting Down The Fireplace
CLASSIC-LINE ECO-LINE Instruction manual Shutting down the fireplace Before shutting down the fireplace, make sure there are no flames or unburned wood in the hearth. Failing to check this or closing the combustion air supply too soon could result in deflagration (= explosive... -
Page 19: Closing/Opening The Fireplace Door
CLASSIC-LINE ECO-LINE Instruction manual Closing/opening the fireplace door Axinit, Ellipse, Jade, Larimar, Lumo, Prisma, Prismalo, Saphir 7/10 A: Door locked → Cannot be swung open B: Door unlocked → Can be swung open Unlocking 1 Raise the fireplace door a minimum of 20 cm... - Page 20 CLASSIC-LINE ECO-LINE Instruction manual Pi, Pi-ccolo Locking devices underneath - Closing and securing the the side doors happens in reverse order. - Both side doors can swing open. 1./3 - The front door can not wing open ! Unlocking and swing open...
-
Page 21: Cleaning The Fireplace
Never clean the glass when it is hot! Protect the chimney enclosure and the flooring Use only Rüegg cleaner, water and a soft cloth. Abrasive products, brushes and sponges must never be used! Further information can be found in our online store on www.ruegg-cheminee.com. -
Page 22: Maintenance
CLASSIC-LINE ECO-LINE Instruction manual Maintenance Wait until the system has completely cooled down before any maintenance operations. Figure 1 Protect the chimney enclosure and the flooring. Door hinge-side guide (figure 1) The door hinge-side guide should be cleaned and lubricated at least twice a season and more frequently if the fireplace is used intensively. -
Page 23: Troubleshooting
CLASSIC-LINE ECO-LINE Instruction manual Troubleshooting The chimney draught is inadequate and/or smoke spreads into the room. Check the following: • The fireplace door is closed. • The smoke regulator* is open. • The chimney flue is pre-heated. • The combustion air regulator* and the combustion air control are open. -
Page 24: Nameplate
CLASSIC-LINE ECO-LINE Instruction manual Nameplate Should any problems arise, and before contacting your dealer, you should note the following information to be found on the nameplate. Your dealer needs this information to provide prompt, high-quality customer service. Figure 1 Model:... -
Page 25: Spare Parts
Failure to comply will result in the loss of your warranty rights! Accessories Rüegg Cheminée has a wide range of top-quality accessories specially designed for your fireplace. You should consult your dealer or go on our website - www.ruegg-cheminee.com. - Page 26 CLASSIC-LINE ECO-LINE Instruction manual Notes...
- Page 28 89.90.00434 ba_classic-line_rev5_en_09.2013...
