Danfoss PAH 2-6.3 Disassembling And Assembling page 5

Instruction Disassembling and assembling PAH 2-6.3, PAHT 2-6.3 and PAHT G 2-6.3
NB: Items 10.2.a. through 10.2.c. concern
PAH 4-6.3, PAHT 3.2-6.3 and
PAHT G 3.2-6.3 only
10.2.a. Remove the retaining guide.
10.2.c. Remove the spring.
NB: The following items concern PAH 2-6.3,
PAHT 2-6.3 and PAHT G 2-6.3 only
11. Loosen the valve plate using two screw-
drivers. Place one of the screwdrivers in the
slot of the valve plate.
180R9094 / 521B0985 / DKCFN.PI.011.N4.02 / 09.2013
10.2.b. Remove the spring guide.
12. Remove the valve plate.
5
