b
Operating temperature may vary based on the limitations of installed SFPs. Refer to the RUGGEDCOM
SFP Transceivers Catalog for SFP temperature ratings.
c
Non-condensing
5.7
Mechanical Specifications
Weight
Ingress Protection
Enclosure
5.8
Dimension Drawings
Note
All dimensions are in millimeters, unless otherwise stated.
Note
Dimensional tolerances are in accordance with ISO 2768-mK, unless otherwise stat-
ed.
RUGGEDCOM RSG2300
Installation Manual, 01/2020, C79000-G8976-1046-15
5.2 kg (11.5 lbs)
IP20
18 AWG Galvanized Steel
Technical Specifications
5.7 Mechanical Specifications
35
