16 | Hardware Installation and Maintenance Guide for SG5600 Appliances
Item Port
5 Management port 2 on
the E5600SG
controller
6 Four network ports on
the E5600SG
controller
Related concepts

Port bond modes for the E5600SG controller ports

Related tasks
Gathering installation information
Cabling the appliance
Related information
VMware installation
Red Hat Enterprise Linux or CentOS installation
Ubuntu or Debian installation
Port bond modes for the E5600SG controller ports
When configuring network links for the E5600SG controller ports, you can use port bonding for the
10-GbE ports that connect to the Grid Network and optional Client Network, and the 1-GbE
management ports that connect to the optional Admin Network. Port bonding helps protect your data
by providing redundant paths between StorageGRID networks and the appliance.
Related tasks
Configuring network links
Network bond modes for the 10-GbE ports
The 10-GbE networking ports on the E5600SG controller support Fixed port bond mode or
Aggregate port bond mode for the Grid Network and Client Network connections.
Fixed port bond mode
Fixed mode is the default configuration for the 10-GbE networking ports.
Type of port
1-Gb (RJ-45) Ethernet
10-GbE (optical)
on page 18
on page 25
on page 35
Function
• Can be bonded with management
port 1 if you want a redundant
connection to the Admin Network.
• Can be left unwired and available
for temporary local access (IP
169.254.0.1).
• Can be used to connect the
E5600SG controller to a service
laptop during installation, if a
DHCP-assigned IP address is not
available.
Connect to the Grid Network and the
Client Network for StorageGRID. See
"10-GbE port connections for the
E5600SG controller."
