Linear Logic ScanGauge II Installation And Operation Manual page 12

• Maximum Coolant Temperature
• Maximum Engine RPM
• Average Speed
• Average Fuel Economy
• Trip Miles
• Trip Elapsed Time
• Trip Fuel Used
• Trip Fuel Cost
The TANK trip will not show Maximums but will show the following:
• Fuel Used Since last Fill-up
• Fuel Remaining
• Distance Driven Since last Fill-up
• Distance Remaining before tank is empty
• Time Driven Since last Fill-up
• Time Remaining before tank is empty
The following display is a typical trip display. Pressing the upper right
or left button will allow you to change the displayed information for the
trip/tank
For instance, pressing the upper right button will select the amount of
fuel consumed on the trip. The following display is typical of the
resulting output. The Current trip can be reset manually at any time by
RESET
pressing
minutes of the ScanGaugeII being asleep.
RESET
Pressing the
following display would be seen:
< 15.3 MPG
<CURRENT
. It will also be automatically reset after about 3
< 5.2 GALLONS >
<CURRENT
button will reset all of the current trip data. The
>
RESET>
RESET>
10
