Honeywell Limitless WGLA Series Installation And Technical Manual

Wgla limit switch used in conjunction with the limitless wpmm series
Hide thumbs

Advertisement

Quick Links

Installation and Technical Manual for the
Limitless™ Series WGLA Limit Switch
used in conjunction with the Limitless™ WPMM Series
WARNING
PERSONAL INJURY
• DO NOT USE these products as safety or emergency
stop devices or in any other application where failure of
the product could result in personal injury.
Failure to comply with these instructions could result in
death or serious injury.
WARNING
Honeywell does not recommend using devices for critical
control applications where there is, or may be, a single point
of failure or where single points of failure may result in an
unsafe condition. It is up to the end-user to weigh the risks
and benefits to determine if the products are appropriate for
the application based on security, safety and performance.
Additionally, it is up to the end-user to ensure that the
control strategy results in a safe operating condition if any
crucial segment of the control solution fails.
Honeywell customers assume full responsibility for learning
and meeting the required Declaration of Conformity,
Regulations, Guidelines, etc. for each country in their
distribution market.
Failure to comply with these instructions could result in
death or serious injury.
Sensing and Control
WARNING
RF EXPOSURE
• To satisfy FCC RF exposure requirements for mobile
transmitting devices, a separation distance of 20 cm or
more should be maintained between the antenna of this
device and persons during device operation To ensure
compliance, operation at closer than this distance is not
recommended. The antenna used for this transmission
must not be co-located in conjunction with any other
antenna or transmitter.
Failure to comply with these instructions could result
in death or serious injury.
WARNING
• The WGLA must be installed in accordance with the
requirements specified in this document. See Section 3
and Section 4 for EIRP requirements. Only the specified
EIRP power settings, antenna types and gains and cable
lengths (attenuation) as outlined in this document are
valid for WGLA Series installations.
CAUTION
• Power to the WGLA should not be applied (ensure
battery is removed) during installation of antenna as
damage could occur to the WGLA electronics.
50051863
