Specifications - Fluke 705 Manual

Fluke 705
Calibration Information

Specifications

Product specifications are provided Tables 1 and 2. These specifications are based on a 1-year calibration cycle and
apply from 18 ºC to 28 ºC (64 ºF to 82 ºF) unless stated otherwise. Accuracy specifications are given as follows:
± ( [ % of reading ] + [ number of least significant digits ] ).
Maximum voltage between any
terminal and earth ground or
between any two terminals
Display:
Operating Temperature:
Storage Temperature:
Temperature Coefficient:
Relative Humidity:
Operationing Altitude:
Power Requirements:
Battery Life (Typical):
Shock, Vibration:
Size (H x W x L):
Weight:
Safety
Certification
Function
DC Volts Input
DC mA Input
DC mA Output
Source mode:
Simulate mode:
Loop Power
Percent display
Input/Output protection
2
Table 1. General Specifications
30 V
0 to 28 V with 0.001 V resolution, 0 to 24 mA with 0.001 mA resolution
-10 °C to 55 °C
-40 °C to 60 °C
± 0.005 % of range per °C for -0 °C to 18 °C and 28 °C to 55 °C
95 % to 30 °C,
75 % to 40 °C,
45 % up to 50 °C,
35 % up to 55 °C
3000 meters maximum
Single 9 V battery (ANSI/NEDA 1604A or IEC 6LR61)
Source Mode: 18 hours; 12 mA into 500 Ω
Measure / Simulate Mode: 50 hours
1 meter drop test
Random vibration 2 g @ 5 to 500 Hz
32 mm x 87 mm x 187 mm (1.25 in x 3.41 in x 7.35 in)
349 g (12.3 oz). With Holster and flex-stand: 601 g (21.2 oz)
Certified as compliant to CAN/CSA C22.2 No. 1010.1:1992.
Complies with ANSI/ISA S82.01-1994
and
Table 2. Accurcy Specifications
Range
+ 28 V
24 mA
0 mA to 24 mA
0 % -100 % - 0 % 40 second smooth ramp
0 % -100 % - 0 % 15 second smooth ramp
0 % -100 % - 0 % Stair-step ramp in 25 % steps, pausing 5 seconds at each step
Compliance: ≥ 1000 Ω at 20 mA
External loop voltage requirements: 24 V nominal, 30 V maximum, 12 V minimum
≥ 24 V
- 25 % to 125 %
Input/Output protection on mA range: resettable, nonreplaceable 0.1 A fuse.
Resolution
0.001 V
0.001 mA
0.001 mA
Accuracy
± (0.025 % + 1)
±( 0.02 % + 2)
± (0.02 % + 2)
