Fluke 705, 707, 707Ex and
Complete family of volt/mA calibrators.
30
Specifications – 705, 707, 707Ex and 715
Functions
Voltage measurement
Range
Resolution
Accuracy
Current measurement
Range
Resolution
Accuracy
Current sourcing
Range
Accuracy
Drive capability
Loop power while measuring mA
Voltage sourcing
Display current and % of span
Auto step, auto ramp
Span Check
Battery life
1
Will over-range to 24 mA
Recommended accessories – 705, 707, 707Ex and 715 Calibrators
TL28A
See page 39
For more information, go to www.MyFlukeStore.com
715 Loop Calibrators
Fluke 707 and 705
Two powerful models to choose from
•
Innovative output adjustment dial on 707 provides
1 µA and 100 µA resolution and one-hand operation
•
Large display and simple interface for ease of use
•
Simultaneous mA and % readout for quick, easy
interpretation of readings
•
mA accuracy of 0.015 % on the Fluke 707 and 0.02 %
on the 705
•
HART
™
mode on 707 connects 250 ohm resistor in
series with 24 V loop for compatibility with HART
communicators
•
Push button 25 % steps for fast, easy linearity checks
•
"Span Check" for fast confirmation of zero and span
•
Selectable slow and fast linear step ramp provide
ramping outputs for valve slewing, remote testing
and loop functional tests
•
24 V internal loop supply, so you can power and read
a transmitter at the same time without carrying a DMM
•
0-20 mA or 4-20 mA default start up modes.
Fluke 707Ex Intrinsically Safe
Loop Calibrator
All the great features of the 707 plus certification in accor-
dance with the ATEX directive (Ex II 2 G EEx ia IIC T4) and
Factory Mutual W.I. Class 1, Div. 2 Groups A-D.
Fluke 705, 707 and 707Ex
0 to 28 V
1 mV
705: 0.025 % Rdg + 1 LSD
707, 707Ex: 0.015 % Rdg + 2 LSD
0-24 mA
0.001 mA
705: 0.02 % Rdg + 2 LSD
707, 707Ex: 0.015 % Rdg + 2 LSD
0-20 mA or 4-20 mA
1
705: 0.025 % Rdg + 2 LSD
707, 707Ex: 0.015 % Rdg + 2 LSD
705: 1000 Ω @ 24 mA
707: 1200 Ω @ 24 mA
707Ex: 700 Ω @ 20 mA
24 V
N/A
Yes
Yes
Yes
18 hours typical, at 12 mA
TL220
C25
See page 39
See page 44
Fluke 715
0 to 100 mV
0 to 10 V
10 µV
1 mV
0.02 % Rdg + 2 LSD
0-24 mA
0.001 mA
0.015 % + 2 LSD
0-20 mA or 4-20 mA
1
0.015 % Rdg + 2 LSD
1000 Ω @ 24 mA
24 V
0 to 100 mV or 0 to 10 V
mA or %
No
No
18 hours typical, at 12 mA
C550
PV350
See page 44
See page 47
Troubleshooting process loops
Application Note
(Literature code 1989137)
In process systems, problems
with the loop can bring things
to a screeching halt. In this
application note, find out how to
use Fluke test tools to
identify
current
loop
problems
such as
noise,
ripple and
drift.
Fluke 715 Volt/mA Calibrator
•
Source voltage to 100 mV or 10 V
•
Measure loop current (0-20 mA,
4-20 mA) signals with 0.015 %
accuracy and 1 µA resolution
•
Measure voltage output process
signals from PLCs, transmitters
•
Source or simulate 24 mA loop current
•
24 V loop supply with simultaneous
current measurement
Included accessories
Fluke 705, 707 and 707Ex: C81Y
Protective holster, TL75 Test Leads,
AC72 Test Clips, instruction sheet
(14 languages).
Fluke 715: C81Y Protective Yellow
Holster with Flex-Stand, test leads
and alligator clips, single 9 V
alkaline battery, instruction sheet
(14 languages).
Ordering information
Fluke-705
Loop Calibrator
Fluke-707
Loop Calibrator
Fluke-707Ex IS Loop Calibrator
Fluke-715
Volt/mA Calibrator
