Microphone
Camera with LED
Loudspeaker
Call button +
Nameplate

C- WIRING / INSTALLING

C1- Wiring diagram
1 2 A B
MASTER
1 2 A B
1 2 A B
1 B
2 A
10 EN
Rainy cover
SW2 SW1 LK-
Volume adjust
Anti-vandal fixing
screws for outdoor
station
SW2 SW1 LK- LK+
SW2 SW1 LK- LK+ 2
Polarity
free
0 à 50 m - 0,75 mm
50 à 100 m - 1 mm
1 2 A B
EXT 1.
1 2 A B
EXT 2.
C2- Installing

Indoor monitor

LK+ 2 1
Connection port
Backlit name plate
with automatic
light sensor

Outdoor station

2 1
Center of
lense
1
12V - 700mA
+
-
500
(mm)
EN
11
