List of Tables
L T
IST OF ABLES
1. D3LX Front-Panel Description and Status LEDs .......................................................................................... 4
2. Tip and Ring Assignments for Protection Switching Applications ............................................................... 8
3. Chassis Port Description .............................................................................................................................. 19
4. Navigational Keys for the Craft Interface Screens During Telnet Sessions ................................................ 22
5. D3LX CO Configuration Fields-SCU V3.7 or later.................................................................................... 24
6. D3LX Alarm Level Defaults........................................................................................................................ 26
7. Unit Configuration Fields-D3RCAM Version 1.0 or later.......................................................................... 35
8. Troubleshooting ........................................................................................................................................... 36
9. D3LX Module Specifications....................................................................................................................... 37
viii August 30, 2002
LTPS-UM-8013-03
D3LX CO and RMT Modules
