LTPS-UM-8013-03
P
ERFORMANCE
Use this procedure to monitor the performance of modules on both
the near and far end of D3LX systems.
1
From the Main menu, select 7. Performance
Monitoring.
2
From the Performance Monitoring menu, select
DS3/E3 PM Configuration (as shown in
3
In PM Reports, select DS3/E3 Far End PM Configuration.
To change the type of report, select the Group and Circuit, then select Local or Remote, 15 Minute, Daily, or
Summary.
4
Use
,
SPACEBAR
to your requirements, then assign the selections by pressing
Figure 17. Performance Monitoring Menu–DS3/E3 PM Configuration Shown
D3LX CO and RMT Modules
M
ONITORING
,
,
, and
to select the group and slot to display, populate each data field according
August 30, 2002
7. Performance Maintenance
Figure
17).
.
ENTER
Local Configuration
1. PM Configuration
2. PM Reports
29
