Appendix A - Specifications; D3Lx Module Specifications - ADC Soneplex D3LXC-FCA100 User Manual

LTPS-UM-8013-03
A
PPENDIX
Parameter
DS3
Input Frequency
Input Level
Interface Standard
Output Signal
Line Buildout - Software selectable
Input/ Output Impedance
Power
Consumption/Dissipation
Supply Voltage
Supply Current
Optical
Fiber Cable
Transmit Wavelength
D3LX CO
D3LX RMT
Optical Connector
Transmit Device
Receive Device
Transmit Power
Receive Dynamic Range
Minimum Optical Budget
BER Threshold for Protection Switching
BER Threshold for Minor Alarm
Dimensions
Size (H x W x D)
Weight
Environmental
Operating Temperature
Storage Temperature
Operating Humidity
Storage Humidity
D3LX CO and RMT Modules
A - S
PECIFICATIONS
Table 9. D3LX Module Specifications
Specifications
44.736 Mbps
+5.7 dBm to -7.3 dBm
DSX-3 Bipolar
Within DSX-3 template
0 to 225, 226 to 450 ft.
75 ± 5%
6W
-42.0 to -56.0 Vdc
110 mA typical @ -48V
125 mA max. @ -48V
9/125 m single-mode
1550 nm ± 40 nm
1310 nm ± 40 nm
SC or FC
Laser
PIN Photodiode
-7 dBm ± 2 dBm
-5 dBm to -23 dBm
13 dB
-4
8.5 x 10 to 1 x 10
-4
1 x 10 to 1 x 10
4.4 x 1.4 x 9.2 in.
(11.2 x 3.6 x 23.4 cm)
1.0 lb (.45 kg)
-40°C to +65°C (-40°F to + 149°F)
-40°C to +80°C (-40°F to + 176°F)
5% to 95%
5% to 95%
August 30, 2002
Remarks
Nominal
Per catalog number
Average Power
Software selectable threshold
-10
Software selectable threshold
-10
Each module
No condensation
No condensation

Appendix A - Specifications

37
