LTPS-UM-8013-03
1
From the Main menu, select 3. Unit Configuration.
2
Within the Unit Configuration screen (see
the D3LX circuit you want to configure, based on the module's position in the remote unit.
3
Select each field parameter and move from field to field as shown in
pressing
.
ENTER
Leave Unit Service State field set to OOS (Out of Service) until the Unit Equip State has been set.
This prevents false alarms. Set the Unit Service State to IS (In Service).
4
Repeat Steps 1 and 2 for each D3LX RMT system installed in the chassis.
Table 7. Unit Configuration Fields–D3RCAM Version 1.0 or later
Field Name
Type
Unit Equip State
Toggle
Unit Service State
Toggle
Unit Protect State
Toggle
DS3 Provisioned
Toggle
DS3 Service State
Toggle
Optical Service State
Toggle
Optical BER Alarm
Toggle
Threshold
Optical BER Switch
Toggle
Threshold
DS3 Remote LBO
Toggle
DS3 Local LBO
Toggle
D3LX CO and RMT Modules
Figure 22 on page
Options
EQUIPPED
Establishes communication with D3RCAM.
Module must be set to EQUIPPED before
remaining selections are allowed.
UNEQUIPPED
No communication with D3RCAM.
IN SERVICE
Places the unit in service and allows equipment
alarm reporting by the D3RCAM. Must be set to
IS for reporting of equipment alarms.
OUT OF SERVICE
Removes unit from service and stops
equipment alarm reporting by the D3RCAM.
PROTECTED
Line protection
UNPROTECTED
No protection
YES
Brings up DS3 default settings and allows
configuration changes.
NO
No configuration changes allowed.
IN SERVICE
Select IS after completing the remaining con-
figurations.
OUT OF SERVICE
Leave this field at OUT OF SERVICE (versus IN
SERVICE) at this time to avoid undesirable
reporting of alarms.
IN SERVICE
Places facility in service and enables T3 alarm
reporting by the D3LX RMT.
OUT OF SERVICE
Removes facility from service and stops T3
alarm reporting by the D3LX RMT.
Set to OFF or set
The average Bit Error Ratios of both the
-6
-10
between 10
and 10
incoming optical signals are monitored by the
D3LX RMT. By monitoring BERs, the D3LX CO
is capable of triggering a minor alarm when any
of the monitored signals degrades below the
BER threshold level.
-4
Range from 10
to
Sets the threshold at which the APS will be
-10
10
executed.
0–225 ft., 226–450 ft.
The DS3 signal output provides standard DSX
signal levels which can be compensated for at
various distances, such as cable length.
0–225 ft., 226–450 ft.
The DS3 signal output provides standard DSX
signal levels which can be compensated for at
various distances, such as cable length.
August 30, 2002
34), select the Group number that corresponds to
Table
7. Assign the selections by
Description
Remote Configuration
Default
UNEQUIPPED
OOS
Unprotected
NO
OOS
OOS
-8
10
-6
10
0–225 ft.
0–225 ft.
35
