- Page 1 Invacare® Etude Plus Etude Plus, Etude Plus Low EN Bed User Manual This manual MUST be given to the user of the product. BEFORE using this product, read this manual and save for future reference.
- Page 2 All rights reserved. Republication, duplication or modification in whole or in part is prohibited without prior written permission from Invacare. Trademarks are identified by ™and ®. All trademarks are owned by or licensed to Invacare Corporation or its subsidiaries unless otherwise noted.
-
Page 3: Table Of Contents
Contents General ........4 About this manual . -
Page 4: General
Etude Plus Invacare® may repair the fault or replace the component. The 1 General warranty provided by Invacare® does not cover additional costs (transport, packaging, labour, sundry expenses, etc. are for the 1.1 About this manual customer’s account). Thank you for choosing an Invacare product. -
Page 5: Safety
Safety 2 Safety IMPORTANT! – Do not roll over the mains cable. Do not bring mains cable into moving parts. 2.1 General warning – Disconnect the plug from the mains before moving the bed. WARNING! – Make sure that no cables (mains or from other Risk of entrapment / suffocation equipment) are jammed or damaged, when the bed is There’s a risk of entrapment / suffocation between... -
Page 6: Setup
Etude Plus Mattress support 3 Setup 3.1 Receiving the bed When you receive the bed, check the packaging. If the bed shows any signs of damage upon delivery, please follow terms of delivery Place the two inserts in the head end of the mattress support. -
Page 7: Dismantle The Bed
Setup In order to prevent the cables from being torn apart when activating the motors, follow the instructions below. Connect the cables of the bed end motors (head and foot end) directly to the control box. The plug of the thigh motor must be directed through the opening of the supporter for the backrest motor and then be connected to the control box. -
Page 8: Operating The Bed
Etude Plus 4 Operating the bed WARNING! Risk of injury – The bed’s castors must be locked whilst nursing a 4.1 Operating the hand control unit patient in bed or when using any positioning function. – The bed’s castors must be locked when the patient... -
Page 9: Accessories
– To avoid the patient from entrapping or accidentally Invacare or via homepage. falling from the mattress support, it is essential that the gliding shoes are correctly guided into the bed end 5.2 Side rails... -
Page 10: Lifting Pole
Etude Plus Dismounting Loosen the cord. The lifting handle can now be adjusted to the desired height. Lower the side rail. Press the cord together and check that the cord is locked in the Dismount one end at a time. Lift the lower bar, so that the spring cord lock by pulling the handle. -
Page 11: Shipping Brackets / Transport Brackets
Accessories * both Line side rails standard and extendable. Min. density: 38kg/m 5.6 Shipping brackets / Transport brackets 1567454-A... -
Page 12: Maintenance
Etude Plus 6 Maintenance 6.1 Maintenance schedule Important – Service and maintenance of the bed must only be performed by personnel who have received the necessary instruction or training. With normal daily use, service must be carried out according to the service schedule after two years of use and thereafter every second year. -
Page 13: After Use
After Use 7 After Use 7.1 Waste disposal This product has been supplied from an environmentally aware manufacturer that complies with the Waste Electrical and Electronic Equipment (WEEE) Directive 2012/19/EU. This product may contain substances that could be harmful to the environment if disposed of in places (landfills) that are not appropriate according to legislation. -
Page 14: Troubleshooting
Etude Plus 8 Troubleshooting 8.1 Troubleshooting electrical system Remedy Symptom Possible cause Mains is not connected Connect mains Mains indicator does not light up Fuse in the control unit is blown Replace the control unit Control unit is defective Replace the control unit... -
Page 15: Technical Data
77.3 kg accessories Etude Plus auto-regression, complete, excluding 82.7 kg accessories Etude Plus bed end with extra plate – 1 piece 20.6 kg Etude Plus bed end without extra plate – 1 piece 17.9 kg Mattress support, standard head end 24.1 kg... -
Page 16: Electromagnetic Compliance (Emc)
Etude Plus 9.5 Electromagnetic compliance (EMC) Guidance and manufacturer´s declaration – electromagnetic emission The medical bed is intended for use in the electromagnetic environment specified below. The customer or the user of the bed should assure that it is used in such an environment. - Page 17 Technical data Portable and mobile RF communications equipment should be used no closer to any part of the medical bed including cables, than the recommended separation distance calculated from the equation applicable to the frequency of the transmitter. Recommended separation distance: Conducted RF IEC 61000-4-6 Radiated RF...
- Page 18 Notes...
- Page 19 Notes...
- Page 20 Invacare Sales Companies Ireland: United Kingdom: Invacare Ireland Ltd, Invacare Limited Unit 5 Seatown Business Campus Pencoed Technology Park, Pencoed Seatown Road, Swords, County Bridgend CF35 5AQ Dublin Tel: (44) (0) 1656 776 222 Tel : (353) 1 810 7084...
