Electric Height Adjustable Tables
ASSEMBLY INSTRUCTIONS
Rectangular or Square Columns
CORNER UNIT + 1200 TOPS
1. Snap together motor cable ends and leg
• Snap together motor cable ends and leg cables. (Figure A)
cables. (Figure A)
2. Plug the other end of the motor cable to the
• Plug the other end of the motor cable to the control box.
control box.
3. Plug control panel cord into control box.
• Plug control panel cord into control box.
4. Install anti-collision dongle next to control
panel cord. (Figure B) (Rectangular legs only)
5. Last, plug in mains cable to control box.
• Install anti-collision dongle next to control panel cord. (Figure B)
6. Secure cables using provided cord clips and
(Rectangular legs only)
velcro strips.
• Last, plug in mains cable to control box.
• Secure cables using provided cord clips and velcro strips.
Series:
RECTANGULAR OR SQUARE COLUMNS
Figure B
FIGURE B
Control
CONTROL
Panel
PANEL
CORD
Cord
Motor Cable
MOTOR CABLE
ELECTRIC ADJUSTABLE HEIGHT
BASE ASSEMBLY
(CORNER UNIT AND 120° TABLES)
Anti-collision dongle
ANTI-COLLISION DONGLE
(RECTANGULAR LEGS ONLY)
(Rectangular legs only)
Figure A
FIGURE A
MAINS
Mains Cable
CABLE
Leg Cable
LEG CABLE
Part #:
9 | OFS BRANDS
