- Page 1 Operating instructions Retro-reflective sensor O6P7xx...
-
Page 2: Table Of Contents
7�2�2 Set sensitivity with prismatic reflector / reflective tape and object ������10 7�2�3 Setting the maximum sensitivity ���������������������������������������������������������10 8 Operation ����������������������������������������������������������������������������������������������������������� 11 9 Maintenance, repair, disposal ���������������������������������������������������������������������������� 11 1 Preliminary note Technical data, approvals, accessories and further information at www�ifm�com� 1.1 Symbols used ► Instructions > Reaction, result... -
Page 3: Safety Instructions
[…] Designation of keys, buttons or indications → Cross-reference Information Supplementary note� Important note Non-compliance may result in malfunction or interference� 2 Safety instructions • Read this document before setting up the product and keep it during the entire service life� •... -
Page 4: Functions And Features
Position of the product label Explanatory label 3 Functions and features In conjunction with a prismatic reflector or reflective tape the retro-reflective sensor detects objects and materials without contact and indicates their presence by a switching signal� 4 Installation ► Fit the prismatic reflector or the reflective tape behind the object to be detected� ►... -
Page 5: Operating And Display Elements
5 Operating and display elements 1: LED green - operation, stability indication 2: OUT OFF button 3: LED yellow - switching output active 4: OUT ON button 5.1 Stability indication The green LED is on when the supply voltage is applied and the sensor signal is stable�... -
Page 6: Electrical Connection
6 Electrical connection The unit must be connected by a qualified electrician� ► The national and international regulations for the installation of electri- cal equipment must be adhered to� ► Ensure voltage supply to EN 50178� ► Disconnect power� ► Connect the unit as follows: 6.1 PNP M12 pigtail connector Cable... -
Page 7: Settings
7 Settings 7.1 Settings on the sensor 7.1.1 The sensor is to switch when the object is detected ► Position the object� Fig� 1 ► Press [OUT ON] for > 2 s� > The yellow LED flashes� > The setting of the sensitivity with object is made by releasing [OUT ON]�... -
Page 8: 7�1�4 Programming Unsuccessful
IO-Link hardware and software can be found at www�ifm�com� 7.2.1 Adjustable parameters Among others, the following parameters can be set via IO-Link� A table of all adjustable parameters can be found at www�ifm�com/de/io- link� Parameter Values... - Page 9 Parameter Values Description Default name Teach SP1 TP2 2� Part of the teach sequence to set switch N� A� point SP1 by teach without object� The second part of the teach sequence has to be carried out after the first part� TI Result�State - Idle Teach-in status;...
-
Page 10: 7�2�2 Set Sensitivity With Prismatic Reflector / Reflective Tape And Object
7.2.2 Set sensitivity with prismatic reflector / reflective tape and object ► Start the LR DEVICE software� ► Align the retro-reflective sensor to the object (Fig. 1). ► Press [Teach SP1 TP1] in the LR DEVICE software� ► Align the retro-reflective sensor to the prismatic reflector or reflective tape (Fig. -
Page 11: Operation
► For cleaning do not use any solvents or cleaning agents which could damage the plastic parts� ► After use dispose of the unit in an environmentally friendly way in accordance with the applicable national regulations� Faulty sensors must only be repaired by the manufacturer� Technical data and further information at www�ifm�com...
