Well AVR-REL-500-WL User Manual

Automatic voltage regulator
Hide thumbs
1
2
3
4
5
6
7
Table of Contents

Advertisement

Quick Links

Thank you for choosing a WELL product. Please read carefully the following instructions and keep them within
reach.
Please read and save this manual!
Thank you for selecting this smart automatic voltage regulator (AVR). It provides you with a perfect protection for
connected equipment.
This manual is a guide to install and use the AVR. It includes important safety instructions for operation and
correct installation of the AVR. Should you have any problems with the AVR, please refer to this manual before
calling customer service.
This symbol gives information regarding the points important for user's own health
and safety, AVR operation and the safety of your data.
This symbol gives information, warnings, and other suggestions.

TABLE OF CONTENTS

1. Important Safety Instructions ...............................................................................................................1
2. Specifications ...................................................................................................................................2
3. Before Installation ..............................................................................................................................2
a. Contents
4. Introduction to the Regulator.................................................................................................................3
5. Operation of the AVR...........................................................................................................................4
6. Placement.......................................................................................................................................5
7. Maintenances ...................................................................................................................................6
8. Other ..............................................................................................................................................6
USER'S MANUAL
AUTOMATIC VOLTAGE REGULATOR
Model: AVR-REL-500/1000/1500/2000VA-WL
