Specifications:

Range:
Accuracy:
Resolution:
Beam width:
Dead band:
Memory:
Supply voltage:
Loop resistance: 400 Ohms max
Consumption:
Signal output:
Contact type:
Loop fail-safety: 4 mA, 20 mA, 21 mA,

Dimensions:

DL34 Series
31 MAR 11
Rev B
DL14: 2" to 4.1'
(5 cm to 1.25m)
DL24: 4" to 9.8'
(10 cm to 3.0m)
DL34: 8" to 18.0'
(20 cm to 5.5m)
DL14: 0.125" (3mm)
DL24: +/- 0.2% of range
DL34: +/- 0.2% of range
DL14: 0.019" (0.5mm)
DL24: 0.039" (1mm)
DL34: 0.079" (2mm)
DL14/24: 2" (5cm) dia.
DL34: 3" (7.6cm)
DL14: 2" (5 cm)
DL24: 4" (10 cm)
DL34: 8" (20 cm)
Non-volatile
24 VDC (loop)
0.5 W
4-20 mA, two-wire (when
loop powered)
(4) SPST relays 1A
22 mA or hold last
EchoPod
MN204210
Relay fail-safety: Power loss: Hold last
Hysteresis:
Configuration:
Temp. comp.:
Process temp.:
Ambient temp.:
Pressure:
Enclosure type:
Encl. material:
Strain relief mat.: Santoprene
Trans. material:
Cable length:
Cable jacket mat.: Polyurethane
Cable type:
Process mount:
Mount. gasket:
Classification:
Compliance:
Approvals:
DL24 Series
Echo loss: Open, close or
hold last
Selectable
WebCal® PC Windows®
USB 2.0
Automatic
F: 20° to 140°
C: -7° to 60°
F: 31° to 140°
C: -35° to 60°
MWP = 30 PSI
Type 6P encapsulated,
corrosion resistance &
submersible
PC
PVDF
48" (1.2 m)
9-cond., shielded
DL14/24: 1" NPT (1" G)
DL34: 2" NPT (2" G)
Viton®
General purpose
RoHS
CE – DL14/DL24/DL34
cFMus – DL14 only
DL14 Series
