  • Page 1 USER MANUAL ® Mobeye ThermoGuard TwinLog CML2255 SW version 5.n...

  • Page 3: Table Of Contents

    Connect an external power supply (optionally) Connect a sensor to the inputs (optionally) Connect a device to the output (optionally) 4. Programming when using the Mobeye SIM and portal Sign up in the Mobeye Internet Portal Register the Mobeye SIM card...
  • Page 4 5.17 Buttonlock 5.18 Alarm indication 5.19 Low power mode 5.20 Pulse time and output behaviour 5.21 Test message 6. Programming when using own SIM card Program mode Programming the settings by SMS Program at least one telephone number Program threshold values for the temperature 7.
  • Page 5 • Do not let it fall from height. • Do not use in an environment where any inflammable gases, vapors or dust are present or could be present. • Repair of the device may only be carried out by people, trained for Mobeye ® repair.

  • Page 6: General Description

    First of all you’ll have to choose a SIM card to place in the device. You can use the Mobeye SIM card or your own SIM card. The Mobeye SIM card provides access to the Mobeye Internet Portal. In this management environment the device is given additional functions such as online programming, status and history display, more options for forwarding messages and it will monitor test messages (keep alive).

  • Page 7: Standard Behaviour

    - When one of the inputs remain in the alarm status, the CML2255 repeats sending the alarm message via the Mobeye Internet Portal every four hours. - When an external power supply is used and a power failure occurs, the Mobeye CML2255 sends a ‘power failure’ message to Mobeye Internet Portal, to be forwarded to the ‘alarm contacts’...

  • Page 8: Mobeye Cml2255 With Own Sim Card

    ‘service’ contacts. Chapter 5 describes how to influence the standard behaviour. As described, the Mobeye CML2255 will, in addition to calling in the event of an alarm, send various messages to the Mobeye Internet Portal. This is done via data traffic where possible.
  • Page 9 - When the batteries need to be replaced, the Mobeye CML2255 sends a ‘low battery’ SMS text message to the first telephone number (administrator). - When an external power supply is used and a power failure occurs, the Mobeye CML2255 sends a ‘power failure’ SMS text message to the set telephone numbers and calls them.

  • Page 10: Getting Started

    3. GETTING STARTED To get started with the Mobeye CML2255, at least the following steps need to be taken in the following order: 1. Insert the SIM card 2. Connect the temperature sensor(s) 3. Insert the batteries 4. Connect an external power supply (optionally) 5.

  • Page 11: Insert The Batteries

    2 3.4 CONNECT AN EXTERNAL POWER SUPPLY (OPTIONALLY) Although the Mobeye CML2255 is designed to run on batteries, it is possible to use an external power supply. In this mode the module is always connected with the GSM network and therefore always in program mode. When the power fails, the batteries take over and a power failure alarm message is sent.

  • Page 12: Connect A Sensor To The Inputs (Optionally)

    A second sensor can be connected to input 2. 3.6 CONNECT A DEVICE TO THE OUTPUT (OPTIONALLY) The Mobeye CML2255 has an open collector output, which switches after receiving a correct SMS or after an alarm. The output can switch permanently, or just switch...
  • Page 13 The maximum load of the output is 200mA. To switch devices, a relay can be placed behind the output with an input voltage of 12VDC. The required switching voltage of the relay depends on the device connected. NOTE: The output does not work if the CML2255 is battery-operated.

  • Page 14: Programming When Using The Mobeye Sim And Portal

    You will receive an e-mail to confirm the new account. After confirmation login on the portal. If you do not receive this e-mail, please check your spam box or ask Mobeye (info@mobeye.com). 4.2 REGISTER THE MOBEYE SIM CARD...

  • Page 15: Enter The Program Mode

    3 seconds. 4.4 ACTIVATE THE DEVICE IN THE PORTAL If the LED on the outside flashes once per second, you activate the device in the Mobeye Internet Portal by clicking ‘Activate device’, which is written behind the registered SIM card. Contract SIM card + portal “Monitoring”...

  • Page 16: Configuration And Synchronisation

    The device settings can be programmed in the Mobeye Internet Portal. In this way you prepare the settings, to be picked up by the device. Since the Mobeye device is leading in the communication between the portal and the device, the data synchronisation is done after: 1) any message to the portal (e.g.
  • Page 17 Device Settings The device settings can be changed via the Mobeye Internet Portal. To do this, click on the "edit" icon and type in the security code (factory setting is "1111"). See chapter 5 for the description per setting. After saving the new settings, they must be retrieved by the device (synchronized).

  • Page 18: Switching On/Off

    4.7 SWITCHING ON/OFF After the previous steps the Mobeye CML2255 is ready for use. It is armed (switched on) automatically. In order to switch off (disarm) the Mobeye CML2255: - Press the on/ off button at the upper side for 1 second. The green LED switches off to indicate the disarmed status.

  • Page 19: System Reset

    The security code is back to factory settings as well. The SIM card is now disconnected and is visible on the "Add device" screen. The SIM card can be used again in another (or the same) Mobeye device in combination with the portal.

  • Page 20: Possible Settings

    The Mobeye CML2255 has many setting options that influence the behaviour of the module. If connected on the Mobeye Internet Portal, the settings are prepared in the portal (see chapter 4). If your own SIM card is used, programming is done via SMS commands (see chapter 8).

  • Page 21: Set A Minimum And/Or Maximum Temperature Limit

    5.5 LOG INTERVAL When using the Mobeye Internet Portal the Mobeye CML2255 will log values and send these to the portal. The logging interval is the interval in which the measured values are logged (with a timestamp). The data are stored in the system until the next data transfer.

  • Page 22: Unit Of Temperature

    The adjusted temperature will be used in the measurement and reports. Example: the Mobeye CML2255 measures 13 °C. Actual ambient temperature is measured as 13,5 °C. To adjust this difference, +0,5 degrees shall be programmed.

  • Page 23: Power Failure Message

    5.14 POWER FAILURE MESSAGE If the Mobeye CML2255 is powered externally and the power fails, it is able to make phone calls and/or send textual messages. There are three configuration options: Alert, Alarm, Off. Mobeye SIM/Portal Own SIM Alert Message via portal...

  • Page 24: Buttonlock

    (OFF). As default this indication is set to ‘ON’. 5.19 LOW POWER MODE A battery-powered Mobeye CML2255 has the GSM module switched off in stand-by mode. It only switches on if it has to send a message. An externally powered unit always keeps the GSM module open (as factory default).

  • Page 25: Test Message

    The message will update the temperature in the status block. The test message will also be sent if the unit is disarmed. The Mobeye Internet Portal expects the test message and checks the timely receipt. The monitoring of the test messages follows the ‘management by exception’...

  • Page 26: Programming When Using Own Sim Card

    In the situation that the CML2255 is connected to an external power supply, it has continuous network connection and the unit is permanently in program mode. A battery-operated Mobeye CML2255 switches to the program mode after pressing the on/off button for 5 seconds until the LED starts flashing. Alternatively the batteries are re-inserted.

  • Page 27: Programming The Settings By Sms

    In chapter 7.1 all possible SMS commands are listed. 6.3 PROGRAM AT LEAST ONE TELEPHONE NUMBER The Mobeye CML2255 is able to send messages up to 5 telephone numbers. The first telephone number (TEL1) belongs to the administrator. Technical messages (such as battery low) are sent to the administrator only.

  • Page 28: Program Threshold Values For The Temperature

    All limits can be set between -35 ºC and +70 ºC with one decimal. Negative values are entered by placing a “-” in front of the value. To enter a temperature limit, be sure the Mobeye CML2255 is in program mode. Send an SMS text message to the unit with following content:...

  • Page 29: List Of Sms Commands For Programming With Own Sim

    Set telephone number for TEL1: Empty alarm messages TEL5: Delete telephone number DEL1 DEL5 Identification text NAME: 20 characters Mobeye Call on/off CALL: ON, OFF SMS on/off SMS: ON, OFF Lower limit temperature LTL1: -35··· 70 (ºC) sensor 1 and 2...
  • Page 30 Setting SMS Command Options Default value Text at too low TEXT1: 20 characters Temperature temperature sensor 1 1 too low: Text at too high TEXT2: 20 characters Temperature temperature sensor 2 1 too high: Text temperature sensor TEXT3: 20 characters Temperature 1 restoration 1 OK:...
  • Page 31 Setting SMS Command Options Default value Interval ‘test SMS’ TEST: 0···30 (days) Time test message TESTTIME: hhmm Examples: Set phone number 1: 1111 TEL1:0712345678 Delete phone number 1: 1111 del1 Be aware of the space between “1111” and the command.

  • Page 32: Switching On/Off

    7.2 SWITCHING ON/OFF After the previous steps the Mobeye CML2255 is ready for use. It is armed (switched on) automatically. It can be switched on and off by the user-defined time schemes or the button on top. By default this button is ‘locked’, to prevent that the unit can be switched off by mistake.

  • Page 33: System Reset

    Mobeye CML2255, from any telephone number. Before sending the request, make sure the unit is in the program mode (please refer to 6.1). Upon sending the command, the Mobeye CML2255 returns an SMS text message to the originator of the request. The commands are case insensitive.
  • Page 34 The signal strength of the used mobile network can be requested. If the network is weak, it is advised to use a SIM card of another network provider or an external GSM antenna (a Mobeye accessory). The GSM signal strength can be requested by sending following SMS text message:...

  • Page 35: Technical Messages

    7.6 TECHNICAL MESSAGES In the event of technical issues the administrator receives an SMS message. Possible technical messages are: Message Reason Low batteries, external power Power is available, batteries need to be supply OK replaced. No external power supply, No external power supply, batteries are able to batteries OK take over operation in low power mode.

  • Page 36: Status Feedback

    8. STATUS FEEDBACK LED pattern Status Required action Blinking green, 1 second Module not configured Configure at least one on / 1 second off telephone number. 1 green flash every 3 Module is switched on, No action required. seconds powered by batteries Green LED stays on Module is switched on, No action required.
  • Page 37 Publisher. Reprinting, even in summary, is prohibited. This user manual meets the technical requirements at the moment of printing. Changes in technology and equipment are reserved. © Copyright 2019 by Mobeye, version CML2255C-EN191111...
