USER MANUAL
Mobeye
CM-Guard TwinLog
®
CML4055
SW version 1.n

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CM-Guard TwinLog CML4055 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mobeye CM-Guard TwinLog CML4055

Summary of Contents for Mobeye CM-Guard TwinLog CML4055

  • Page 1 USER MANUAL Mobeye CM-Guard TwinLog ® CML4055 SW version 1.n...
  • Page 2 • Do not let it fall from height. • Do not use in an environment where any inflammable gases, vapors or dust are present or could be present. • Repair of the device may only be carried out by people, trained for Mobeye ® repair.

  • Page 3: Table Of Contents

    Connect an external power supply (optionally) Connect a device to the output (optionally) Network connection and program mode 4. Programming when using the Mobeye SIM and portal Sign up in the Mobeye Internet Portal Register the Mobeye SIM card Configuration and synchronisation...

  • Page 4: General Description

    In order to activate the device, a few steps are to be followed. First of all, you need to insert a SIM card. With the Mobeye SIM card, the CML4055 uses the 4G LTE-M network. This network has a strong network coverage, deep penetrability in buildings and also works in remote areas.

  • Page 5: Standard Behaviour

    The Mobeye CML4055 with Mobeye SIM card and registered on the Mobeye Internet Portal, has the following behaviour as factory settings: - In case one of the inputs is activated by a sensor, the Mobeye CML4055 sends an alarm message to the Mobeye Internet Portal. The Portal forwards the alarm as push notification, call (spoken message), text message and/or e-mail to the ‘alarm contacts’.

  • Page 6: Mobeye Cml4055 With Own Sim Card

    The Mobeye CML4055, equipped with your own SIM card, has the following standard behavior as factory settings: - When one of the inputs is activated by a sensor, the Mobeye CML4055 sends an alarm SMS text message and calls the phone numbers programmed in by the user.

  • Page 7: Getting Started

    3. GETTING STARTED To get started with the Mobeye CML4055, at least the following steps need to be taken in the following order: 1. Open the casing and insert the SIM card 2. Connect an analog device or sensor to the input 3.

  • Page 8: Connect An Analog Device Or Sensor To The Input

    When using the Mobeye SIM card: The Mobeye SIM card is PIN code secured and will only work in a Mobeye device. Please do not place it in another device. When using your own SIM card: An own SIM card has a “micro” format, is suitable for the 2G network and can make calls and send text messages.

  • Page 9: Insert The Batteries

    3.5 CONNECT A DEVICE TO THE OUTPUT (OPTIONALLY) The Mobeye CML4055 has an open collector output, which switches after receiving a correct SMS or after an alarm. The output can switch permanently, or just switch for a pulse time after which the output automatically switches back.

  • Page 10: Network Connection And Program Mode

    3.6 NETWORK CONNECTION AND PROGRAM MODE After placing the batteries (and external power) the Mobeye CML4055 will search for the network. The outside LED flashes green and red. This process normally takes 10-30 seconds, in a new device this can take some minutes.

  • Page 11: Programming When Using The Mobeye Sim And Portal

    Follow the instructions on the screen. You will receive an e-mail to confirm the new account. After confirmation login on the portal. If you do not receive this e-mail, please check your spam box or ask Mobeye (info@mobeye.com). 4.2 REGISTER THE MOBEYE SIM CARD...

  • Page 12: Configuration And Synchronisation

    4.3 CONFIGURATION AND SYNCHRONISATION The device settings can be programmed in the Mobeye Internet Portal. In this way you prepare the settings, to be picked up by the device. Since the Mobeye device is leading in the communication between the portal and the device, the data synchronisation is done after: 1) any message to the portal (regular test message, alarm, low batteries).
  • Page 13 Device Settings The device settings can be changed via the Mobeye Internet Portal. To do this, click on the "edit" icon and type in the security code (factory setting is "1111"). See chapter 5 for the description per setting. After saving the new settings, they must be retrieved by the device (synchronized).

  • Page 14: How To Activate The Cml4055

    The message texts can be adapted to your own text. 4.5 HOW TO ACTIVATE THE CML4055 After the previous steps the Mobeye CML4055 is ready for use. It is armed automatically. In order to switch off (disarm) the Mobeye CML4055: - Press the button at the backside for 1 second.

  • Page 15: System Reset

    The security code is back to factory settings as well. The SIM card is now disconnected and is visible on the "Add device" screen. The SIM card can be used again in another (or the same) Mobeye device in combination with the portal.

  • Page 16: Possible Settings

    5. POSSIBLE SETTINGS The Mobeye CML4055 has many setting options that influence the behaviour of the module. If connected on the Mobeye Internet Portal, the settings are prepared in the portal (see chapter 4). If your own SIM card is used, programming is done via SMS commands (see chapter 6).

  • Page 17: Input Type

    10,2). 5.5 LOG INTERVAL When using the Mobeye Internet Portal the Mobeye CML4055 can log analog values and send these to the portal. The logging interval is the interval in which the measured values are logged (with a timestamp). The data are stored in the system until the next data transfer.

  • Page 18: Inactive Time

    4 hours. 5.10 ALARM RESTORE MESSAGE In factory setting, the Mobeye CML4055 will send alarm restore messages if the input type is set to “AN”. If set to “NO” or “NC” it does not send recovery messages.

  • Page 19: Power Failure Message

    "0". 5.13 AUTOMATIC ARMING / DISARMING The Mobeye CML4055 only works if the unit is armed, which is done via the on/off button. It is possible to automatically arm and disarm the unit, based on an arming and/or disarming time scheme. Two schemes can be entered, which can be assigned to the days in the week (e.g.

  • Page 20: Buttonlock

    "OFF" and the pulse time to "5" seconds. 5.17 LOW POWER MODE The low power mode is only important with an externally powered Mobeye CML4055. If the (factory) mode is set to “OFF”, the communication module will always have a network connection.

  • Page 21: Call And/Or Sms (Own Sim Cards)

    turned off as much as possible to minimize power consumption. Note: in low power mode the module cannot be reached via SMS commands. 5.18 CALL AND/OR SMS (OWN SIM CARDS) When using your own SIM card, by default the CML4055 will call and send SMS text messages.

  • Page 22: Programming When Using Own Sim Card

    If the CML4055 is connected to an external power supply, it has continuous network connection and is permanently in program mode. A battery-operated Mobeye CML4055 switches to the program mode after re-inserting the batteries or pressing the button at the back for 5 seconds.

  • Page 23: Program At Least One Telephone Number

    In chapter 7.1 all possible SMS commands are listed. 6.3 PROGRAM AT LEAST ONE TELEPHONE NUMBER The Mobeye CML4055 is able to send messages up to 5 telephone numbers. The first telephone number (TEL1) is mandatory. This number will receive, next to alarm message, also system messages such as battery low and keep- alive message.

  • Page 24: List Of Sms Commands For Programming With Own Sim

    . . . TEL5: Delete telephone DEL1 number . . . DEL5 Identification text NAME: 20 characters Mobeye Interval ‘test SMS’ TEST: 0 ··· 30 (days) Time test message TESTTIME: hhmm Input type input 1 TYPEIN1: AN, NO, NC Input type input 2...
  • Page 25 Setting SMS command Options Default value Use of on/off button BUTTONLOCK: ON (button locked) OFF (unlocked) Low power status LOWPOWER: ON, OFF Call on/off CALL: ON, OFF SMS on/off SMS: ON, OFF Exit delay DELAYEXIT: 0 ··· 999 (sec) Alarm text AN IN1 high TEXT1: 20 karakters Input 1 high Alarm text AN IN1 low...

  • Page 26: How To Activate The Cml4055

    7.2 HOW TO ACTIVATE THE CML4055 After the previous steps the Mobeye CML4055 is ready for use. It is armed automatically. In order to switch off (disarm) the Mobeye CML4055: - Press the button at the backside for 1 second. The green LED switches off to indicate the disarmed status.

  • Page 27: Sms Reports When Using Own Sim Card

    Mobeye CML4055, from any telephone number. Before sending the request, make sure the unit is in the program mode (see 6.1). Upon sending the command, the Mobeye CML4055 returns an SMS text message to the originator of the request. The commands are case insensitive.

  • Page 28: Technical Messages

    7.5 TECHNICAL MESSAGES In the event of technical issues the telephone number programmed in at position 1 (TEL1) receives an SMS message. Possible technical messages are: Message Reason Low batteries, external power Power is available, batteries need to be replaced. supply OK No external power supply, No external power supply, batteries are able to take...

  • Page 29: Status Feedback

    8. STATUS FEEDBACK LED pattern Status Required action Blinking green, 1 second Module not configured Configure at least one on / 1 second off telephone number. 1 green flash every 3 Module is switched on, No action required. seconds powered by batteries Green LED stays on Module is switched on, No action required.
  • Page 30 This product is designed and manufactured in the Netherlands. For more information, visit www.mobeye.com. ® This manual is published by Mobeye All rights, the translation included are reserved. Any reproduction, either photocopy, microfilm or saved in an automated data dictionary, only after written approval of the Publisher.
