KYLAND Technology SICOM3028GPT Series Hardware Installation Manual

Industrial ethernet switches
Hide thumbs Also See for SICOM3028GPT Series:
Table of Contents

Advertisement

Quick Links

SICOM3028GPT Series Industrial Ethernet
Switches Hardware Installation Manual
Publication Data: Sep. 2016
Version: V1.3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SICOM3028GPT Series and is the answer not in the manual?

Questions and answers

Related Manuals for KYLAND Technology SICOM3028GPT Series

Summary of Contents for KYLAND Technology SICOM3028GPT Series

  • Page 1 SICOM3028GPT Series Industrial Ethernet Switches Hardware Installation Manual Publication Data: Sep. 2016 Version: V1.3...
  • Page 2 SICOM3028GPT Series Industrial Ethernet Switches Hardware Installation Manual Disclaimer: Kyland Technology Co., Ltd. tries to keep the content of this manual as accurate and as updated as possible. This document is not guaranteed to be error-free, and we reserve the right to amend it without notice to users.
  • Page 3 Notice for Safety Operation The product performs reliably as long as it is used according to the guidance. Artificial damage or destruction of the device should be avoided. Before using the device, read this manual carefully for personal and equipment safety. Please keep the manual for further reference.
  • Page 4  Do not disassemble the device by yourself. When an anomaly occurs, contact our sales or technical support personnel.  If any part is lost, contact our sales or technical support personnel to purchase the substitute. Do not purchase parts from other channels. ...

  • Page 5: Table Of Contents

    Contents 1 Product Overview .......................1 2 Structure and Interface .......................5 2.1 Front Panel ........................5 2.2 Rear Panel ........................6 2.2.1 1U Interface Module ....................6 2.2.2 0.5U Interface Module ...................7 3 Interface Module Installation ....................8 3.1 Mounting Modes and Steps ..................8 3.1.1 Installing Mounting Brackets ..................9 3.1.2 Inserting a 0.5U Interface Module into an Upper Slot (Slot 2, Slot 4, or Slot 6) ..9 3.1.3 Inserting a 0.5U Interface Module into a Lower Slot (Slot 3, Slot 5, or Slot 7) ..
  • Page 6 5.7 Power Terminal Block ....................26 5.8 Alarm Terminal Block ....................28 6 LEDs ..........................30 7 Switch Access ........................33 7.1 Access through Console Port ..................33 7.2 Access through Telnet ....................35 7.3 Access through Web ....................36 8 Basic Features and Specifications ..................

  • Page 7: Product Overview

    Product Overview 1 Product Overview The series switches include layer-2 switches and layer-3 switches. With modular design, all these switches support IRIG-B, GPS, serial port, HSR, and many other modules for easy expansion. Based on the full gigabit switching platform, the series switches are the first industrial Ethernet switches that employ the IEC61850 modeling technology in the world, achieving unified management.
  • Page 8 Product Overview L3F-MB Layer 3 100M IEEE1588 non-compliant host PS1: power input 1 HV(220AC/DCW), L1(48DC), L3(24DC) PS2: power input 2 HV(220AC/DCW), L1(48DC), L3(24DC), N/A Table 2 Interface Modules (1U) Model SM6.6-Ports-1U Code definition Code option 4GX, 4GE, 2GX2GE Note: Ports: GX/GE 2GX2GE: 1000Base-X, 10/100/1000Base-T(X)
  • Page 9 Product Overview FC05=FC connector, 1310nm, 5km Ports with S: SC40=SC connector, 1310nm, 40km ST40=ST connector, 1310nm, 40km FC40=FC connector, 1310nm, 40km SC60=SC connector, 1310nm, 60km SC80=SC connector, 1550nm, 80km Ports without S or M: Table 4 Other Modules Model Description Applicable to GPS-to-PTP clock synchronization module, SM6.6-GPS-OI-0.5U...
  • Page 10 Product Overview SM6.6-HSR/PRP-GE-0.5 HSR/PRP Redbox module, supports SICOM3028GPT-L3GT-MB, 10/100/1000Base-T(X) ports SICOM3028GPT-L3G-MB Multi functional application module, supports SM6.6-MFA-0.5U 1000Base-X, 10/100/1000Base-T(X) Combo port Note： For the product information listed in these tables, we reserve the right to amend it without notice. To obtain the latest information, you can contact our sales or technical support personnel.

  • Page 11: Structure And Interface

    Structure and Interface 2 Structure and Interface Caution: It is recommended to purchase the port dustproof shield (optional) to keep ports clean and ensure device performance. 2.1 Front Panel Figure 1 Front Panel Table 5 Description of the Front Panel Identifier Description Alarm...

  • Page 12: Rear Panel

    Structure and Interface 2.2 Rear Panel Figure 2 Rear Panel 2.2.1 1U Interface Module  SM6.6-4GX-1U 1-4: four 1000Base-X, 10/100/1000Base-T(X) SFP slots  SM6.6-2GX2GE-1U 1-2: two 10/100/1000Base-T(X) Ethernet ports 3-4: two 1000Base-X, 10/100/1000Base-T(X) SFP slots  SM6.6-4GE-1U 1-4: four 10/100/1000Base-T(X) Ethernet ports...

  • Page 13: U Interface Module

    Structure and Interface 2.2.2 0.5U Interface Module  SM6.6-4GX-0.5U 1-4: four 1000Base-X, 10/100/1000Base-T(X) SFP slots  SM6.6-2GX2M-SC05-0.5U, SM6.6-2GX2S-SC40-0.5U 1-2: two 100Base-FX Ethernet ports (FC/ST/SC connector) 3-4: two 1000Base-X, 10/100/1000Base-T(X) SFP slots  SM6.6-4GE-0.5U 1-4: four 10/100/1000Base-T(X) Ethernet ports (Note: Its appearance is identical with that of SM6.6-4T-0.5U. You can distinguish them by labels on the front panel.) ...

  • Page 14: Interface Module Installation

    Interface Module Installation  SM6.6-2M2T-SC05-0.5U, SM6.6-2S2T-SC40-0.5U 1-2: two 10/100Base-T(X) Ethernet ports 3-4: two 100Base-FX Ethernet ports (FC/ST/SC connector)  SM6.6-4T-0.5U 1-4: four 10/100Base-T(X) Ethernet ports (Note: Its appearance is identical with that of SM6.6-4GE-0.5U. You can distinguish them by labels on the front panel.) ...

  • Page 15: Installing Mounting Brackets

    Interface Module Installation list the models of the interface modules. Note： Not all the slots require interface modules. Choose slots as needed. 3.1.1 Installing Mounting Brackets Before inserting a 0.5U interface module into an upper or lower slot, install mounting brackets on the module as follows: Select an applicable 0.5U interface module.

  • Page 16: Inserting A 0.5U Interface Module Into A Lower Slot (Slot 3, Slot 5, Or Slot 7)

    Interface Module Installation Figure 4 Inserting a 0.5U Interface Module into an Upper Slot Caution:  To insert an interface module into an upper slot, keep the "TOP" identifier on the module facing up.  If the module cannot be pushed into place, do not force it, because too much force may cause damage to the module.
  • Page 17 Interface Module Installation down. Then push the module into the slot along the guide rail slot until it is in position. Figure 5 Inserting a 0.5U Interface Module into a Lower Slot Caution:  To insert an interface module into a lower slot, keep the "TOP" identifier on the module facing down.

  • Page 18: Inserting A 1U Interface Module Into Slot 1

    Interface Module Installation 3.1.4 Inserting a 1U Interface Module into Slot 1 The steps for inserting a 1U interface module into Slot 1 is the same as those for inserting a 0.5U interface module into an upper slot (Slot 2, Slot 4, or Slot 6). For details, see section 3.1.2.
  • Page 19 Interface Module Installation Figure 7 Removing a 1U Interface Module...

  • Page 20: Switch Installation

    Switch Installation 4 Switch Installation 4.1 Dimension Drawing Figure 8 Dimensions (unit: mm) Caution:  As part of the heat dissipation system, the switch housing becomes hot during operation. Please use caution when coming in contact and avoid covering the switch housing when the switch is running.

  • Page 21: Mounting Modes And Steps

    Switch Installation 4.2 Mounting Modes and Steps The series switches support rack mounting by front/rear panel. The following uses mounting by front panel as an example to describe mounting steps. The steps for mounting by rear panel are similar to those for mounting by front panel. Before installation, make sure that the following requirements are met.
  • Page 22 Switch Installation brackets. If there are screws inserted in the screw holes, remove the screws and keep them for future use. As shown in the following figure, use four screws to secure two mounting brackets to the switch respectively. Figure 10 Installing Mounting Brackets ...
  • Page 23 Switch Installation to the rack posts. Step 2: Remove the switch from the rack posts. Then unscrew the mounting brackets to complete dismounting. Caution: Cut off the power and disconnect all cables before mounting, dismounting or moving the equipment.

  • Page 24: Connection

    Connection 5 Connection 5.1 10/100Base-T(X) Ethernet Port 10/100Base-T(X) Ethernet port is equipped with RJ45 connector. The port is self-adaptive. It can automatically configure itself to work in 10M or 100M state, full or half duplex mode. The port can also adapt to MDI or MDI-X connection automatically. You can connect the port to a terminal or network device with a straight-through or cross-over cable.

  • Page 25: 100Base-Fx Ethernet Port

    Connection Figure 13 Connection Using Straight-through/Cross-over Cable Note： The color of the cable for RJ45 connector meets the 568B standard: 1-orange and white, 2-orange, 3-green and white, 4-blue, 5-blue and white, 6-green, 7-brown and white, and 8-brown. 5.2 100Base-FX Ethernet Port 100Base-FX Ethernet port is equipped with FC/ST/SC connector, and each port consists of TX (transmit) port and RX (receive) port.

  • Page 26: 10/100/1000Base-T(X) Ethernet Port

    Connection laser products. Routine operation is not harmful to your eyes, but do not look directly at the fiber port when the device is powered on. 5.3 10/100/1000Base-T(X) Ethernet Port 10/100/1000Base-T(X) Ethernet port is equipped with RJ45 connector. The port is self-adaptive.

  • Page 27: 1000Base-X, 10/100/1000Base-T(X) Sfp Slot

    Connection  Wiring Sequence Figure 16 Connection Using Straight-through/Cross-over Cable Note： The color of the cable for RJ45 connector meets the 568B standard: 1-orange and white, 2-orange, 3-green and white, 4-blue, 5-blue and white, 6-green, 7-brown and white, and 8-brown. 5.4 1000Base-X, 10/100/1000Base-T(X) SFP slot 1000Base-X, 10/100/1000Base-T(X) SFP slot (gigabit SFP slot) requires an SFP optical/electrical module to enable data transmission.

  • Page 28: Gigabit Sfp Optical Module

    Connection T-RJ45 T(X) port 5.4.1 Gigabit SFP Optical Module Figure 17 Gigabit SFP Optical Module An SFP optical module is equipped with LC connector, and each port consists of a TX (transmit) port and an RX (receive) port. To enable communication between Device A and Device B, connect the TX port of Device A to the RX port of Device B, and the RX port of Device A to the TX port of Device B, as shown in the following figure.

  • Page 29: Gigabit Sfp Electrical Module

    Connection 2. View the corresponding connection status LED: If the LED is on, the connection is correct. If the LED is off, the link is not connected. This may be caused by incorrect connection of the TX and RX ports. In this case, swop the two connectors at one end of the fibers.
  • Page 30 Connection the other, only the console port with the Mini USB connector works when both of the two ports are connected. If you select the RJ45 connector, use a DB9-RJ45 console cable to connect the 9-pin serial port of a PC to the console port of the switch. If you select the Mini USB connector, you need to install Mini USB driver.exe on the PC.

  • Page 31: Grounding

    Connection Signal Signal RXD (Receive data) TXD (Transmit data) TXD (Transmit data) RXD (Receive data) GND (Grounding) GND (Grounding)  USB Console Cable Caution: To use the console port with a Mini USB connector, you need to purchase a USB console cable (optional).

  • Page 32: Power Terminal Block

    Connection the switch properly. You need to ground the switch before it is powered on and disconnect the grounding cable after the switch is powered off. The switch provides a grounding screw(see Figure 2) on the rear panel for chassis grounding.
  • Page 33 Connection PWR2: - PWR2: N PWR2: + PWR2: L Caution: For single power supply, only pins 1, 2, and 3 of the terminal block can be connected. Do not use pins 4 and 5.  Wiring and Mounting Step 1: Ground the device properly according to section 5.6. Step 2: Remove the power terminal block from the device.

  • Page 34: Alarm Terminal Block

    Connection sign, because it may cause damage to humans.  Do not remove any part or plug in or out any connector when the device is powered on. 5.8 Alarm Terminal Block The device provides an alarm terminal block on the rear panel for alarm output. When the switch works properly, the normally-open contacts of the alarm relay are closed and the normally-closed contacts are open;...
  • Page 35 Connection Step 3: Insert the alarm terminal block into its socket. Wiring and Mounting should meet following specifications. Table 13 Wiring and Mounting Specifications Terminal Type Required Torque Wire Range (AWG) Terminal Block Plug 4.5-5.0 lb-in for WEIDMUELLER terminal block 12-24...

  • Page 36: Leds

    LEDs 6 LEDs Table 14 Front Panel LEDs State Description Power 1 is connected and operates properly. Power 1 LED-PWR1 Power 1 is not connected or operates abnormally. Power 2 is connected and operates properly. Power 2 LED-PWR2 Power 2 is not connected or operates abnormally. Blinking The CPU operates properly.
  • Page 37 LEDs 10/100Base-T(X) 100M working state (100Base-TX) Ethernet port 10M working state (10Base-T) or no connection 100M working state (100Base-FX) 100Base-FX Ethernet port No connection Effective port connection Port connection status LED- Blinking Ongoing network activities Slot (1-7) Link/ACT (1-4) No effective port connection Table 15 Rear Panel LEDs State Description...
  • Page 38 LEDs 1000M working state (1000Base-TX) Gigabit 10/100M working state (10/100Base-T(X)) or no electrical module connection Effective port connection 1000Base-X, 10/100/1000Base-T(X) SFP Blinking Ongoing network activities slot connection status LED No effective port connection Caution:  The speed LEDs of 100M ports on the front and rear panels of SICOM3028GPT-L2GT-MB, SICOM3028GPT-L2G-MB, SICOM3028GPT-L3GT-MB, and SICOM3028GPT-L3G-MB are never on.

  • Page 39: Switch Access

    Switch Access 7 Switch Access You can access the switch in any of the following ways: 7.1 Access through Console Port Caution: The console ports support RJ45 and Mini USB connectors. You can select either of the two connectors as needed. If you select Mini USB connector for one port and RJ45 connector for the other, only the console port with the Mini USB connector works when both of the two ports are connected.
  • Page 40 Switch Access Figure 28 Creating a Connection Step 4: Connect the communication port in use, as shown in the following figure. Figure 29 Selecting a Serial Port Note： To confirm the communication port in use, right-click [My Computer] and select [Property]. Click [Hardware] →...

  • Page 41: Access Through Telnet

    Switch Access Figure 30 Setting Port Parameters Step 6: Click OK to enter the switch CLI. Then the following commands can be used to perform operations. Table 16 CLI Commands View Command Description General mode SWITCH>enable Enter the privileged mode. Privileged mode SWITCH#show interface vlan 1 Query the default IP address of the switch.

  • Page 42: Access Through Web

    Switch Access Step 2: On the Windows desktop, click Start and Run. The Run dialog box is displayed. Enter "telnet IP address". For example, if the IP address of the serial port module is 192.168.0.2 (default IP address of the device), enter "telnet 192.168.0.2" in the dialog box.

  • Page 43: Basic Features And Specifications

    Basic Features and Specifications 8 Basic Features and Specifications Power Requirements Maximum Voltage Power Identifier Rated Voltage Range Range L3 (24DC) 24VDC 18-36VDC L1 (48DC) 48VDC 36-72VDC 100-240VAC, 50/60Hz; HV (220AC/DCW) 85-264VAC/77-300VDC 110-220VDC Terminal block 5-pin 5.08mm-spacing plug-in terminal block Rated Power Consumption Rated power consumption Physical Characteristics...
  • Page 44 Basic Features and Specifications SICOM3028GPT-L3G, SICOM3028GPT-L3F：368000h SICOM3028GPT-L2GT, SICOM3028GPT-L2FT：359000h SICOM3028GPT-L2G, SICOM3028GPT-L2F：360000h Warranty Warranty 5 years...
  • Page 45 FAX: +86-10-88796678 Website: http://www.kyland.com Email: support@kyland.com Address: Building No.2, Shixing Avenue 30# shijingshan District, Beijing, China For more information about KYLAND products, please visit our website: http://www.kyland.com...

This manual is also suitable for:

Sicom3028gpt-l2gt-mb-ps1-ps2Sicom3028gpt-l2f-mb-ps1-ps2Sicom3028gpt-l3gt-mb-ps1-ps2Sicom3028gpt-l2ft-mb-ps1-ps2Sicom3028gpt-l3ft-mb-ps1-ps2Sicom3028gpt-l3g-mb-ps1-ps2 ... Show all
