- Page 1 SICOM1005R-M12 User’s Manual 200912 SICOM1005R-M12 Industrial Ethernet Switch User’s Manual KYLAND Technology Co., Ltd.
- Page 2 SICOM1005R-M12 User’s Manual 200912 SICOM1005R-M12 Industrial Ethernet Switch User’s Manual Copyright © 2009 KYLAND Technology CO., LTD. All rights reserved. No part of this documentation may be excerpted, reproduced, translated, annotated or duplicated, in any form or by any means without the prior written permission of KYLAND Corporation.
- Page 3 IP67 protection class, solid and sealed case design, low-power fanless design, overcurrent, overvoltage and EMC protection at power input interface, and excellent EMC protection of M12 port make SICOM1005R-M12 applicable in harsh and dangerous industrial environments, providing multiplex guarantee for reliable operation of the system.
- Page 4 SICOM1005R-M12 User’s Manual 200912 Notice for Safety Operation This product performs reliably as long as it is used according to the guidance. Artificial damage or destruction of the equipment should be avoided. Read this manual and put it away for future reference;...
- Page 5 SICOM1005R-M12 User’s Manual 200912 attention of users during operation. The implications of these signs are as follows: Warning: pay special attention to the notes behind the mark, improper operation will lead to serious damage of the switch or injury of the operating personnel.
-
Page 6: Table Of Contents
SICOM1005R-M12 User’s Manual 200912 Table of contents CHAPTER 1: SYSTEM OVERVIEW ......................7 1.1 Product Overview ..........................7 1.2 Product Features ..........................7 1.3 Packing list and unpacking check..................... 7 CHAPTER 2: PERFORMANCE SPECIFICATIONS .................. 9 2.1 System Specifications ........................9 2.2 Service Interface ..........................10... -
Page 7: Chapter 1: System Overview
Chapter 1: System Overview 1.1 Product Overview SICOM1005R-M12 is a 5 M12 ports unmanaged industrial Ethernet switch specially designed by KYLAND Technology CO., LTD. Product features: IP67 protection class, solid and sealed aluminum case, low-power fanless design, overcurrent, overvoltage and EMC protection at power input interface and excellent EMC protection of M12 ports. - Page 8 Before opening the case, place it stably, pay attention to the direction of the packing case and ensure its right side is facing upward, so as to prevent SICOM1005R-M12 falling from the case after opening it. If using a hard object to open the case, do not over extend the hard object into the case to avoid damage of the equipments inside it.
-
Page 9: Chapter 2: Performance Specifications
SICOM1005R-M12 User’s Manual 200912 Chapter 2: Performance Specifications 2.1 System Specifications The system performance specifications of SICOM1005R-M12 industrial Ethernet switch are shown in Table 2-1. Table 2-1 System Specifications Specifications SICOM1005R-M12-5T Quantity of 10/100Base-TX 5 10 /100Base-TX, M12 connectors Standards: IEEE802.3, IEEE 802.3x, IEEE 802.3u Store-and-Forward speed: 148810pps;... -
Page 10: Service Interface
2.3 Service Function The service functions of SICOM1005R-M12 mainly include: LED Indicator The LEDs in top panel of SICOM1005R-M12 indicate the port status including link status and system status. Layer-2 Switching The two commonly used switching technologies: Cut-Through and Store-and-Forward. In Cut-Through, as soon as the switch receive a frame header, it is immediately forwarded without any error checking and processing;... -
Page 11: Chapter 3: Hardware Structure
Case SICOM1005R-M12 case is wall mounting type structure. The entire unit is a six-side-enclosed aluminum case with protection class up to IP67. The figuration of SICOM1005R-M12 case is shown in Figure 3-2 and 3-3. Its contour dimension is 62 ㎜× 56 ㎜×120 ㎜,（width ×height× depth）... -
Page 12: Top Panel
Figure 3-3 Case dimensions of SICOM1005R-M12 3.2.2 Top Panel SICOM1005R-M12-5T Industrial Ethernet switch’s top panel has 5 10/100Base-TX M12 ports, one M12 power input interface, 5 Ethernet ports’ LINK indicators and one power input indicator. The top panel structure is shown as Figure 3-4:... - Page 13 Figure 3-4 SICOM1005R-M12-5T’s top panel Ethernet M12 Ports SICOM1005R-M12-5T offers five 10/100Base-TX Ethernet M12 ports. Each M12 port has self-adaptive function, support MDI/MDI-X auto-connection and can be connected to terminal equipments, servers, hubs or other switches in straight-through or cross-over way. Each port supports IEEE802.3x self-adaptation, so the most suitable transmission mode (half duplex or full...
- Page 14 Figure 3-5 Wiring sequence of Ethernet M12 port LED indicators The indicators on the top panel of SICOM1005R-M12 can show system operation and port status, helping detect and eliminate faults. Table 3-1 describes the meanings of all indication lights on the top panel.
-
Page 15: Bottom Mounting Panel
SICOM1005R-M12 User’s Manual 200912 Figure 3-6 Wiring sequence of M12 power input terminal 3.2.3Bottom mounting panel The mounting panel of SICOM1005R-M12 Industrial Ethernet Switch has 3 screw holes for wall mounting and one grounding screw hole. Grounding The mounting panel of SICOM1005R-M12 has a grounding screw hole. After connecting one terminal of grounding wire with the cold-pressing terminal, fix it to the grounding hole with grounding screws. -
Page 16: Chapter 4: Test Methods
. Then the indicator marking with “P” will keep on. 4.2 TP Port Test Showing as Figure 4-1, after SICOM1005R-M12 is powered on, respectively connect two TP ports in the switch with two test computers by the straight-through cables, and send the “ping”... - Page 17 SICOM1005R-M12 User’s Manual 200912 (WIN2000) or ”command” (WIN98/95), and send ping 192.168.100.10 –l 1000 –t. Test computer 1 returns “Reply from 192.168.100.11:bytes=1000 time<10ms TTL=128”, Test computer 2 returns “Reply from 192.168.100.10:bytes=1000 time<10ms TTL=128”. Ten minutes later, use CTL+C command to get the packet loss rate. If the rate is “0”, it shows that the...
-
Page 18: Appendix A: Twisted-Pair And Pin Distribution
SICOM1005R-M12 User’s Manual 200912 Appendix A: Twisted-pair and Pin Distribution For the connection of 10Base-T/100Base-TX, the twisted-pair must have two pairs of cables. Each pair is distinguished with two different colors. For example, one strand is green, and the other is the alternate of green and white stripes. One end of the cable is equipped with M12 or RJ45 connector and the other end is RJ45 connector. - Page 19 SICOM1005R-M12 User’s Manual 200912 Unshielded twisted- pair (UTP) or shielded twisted-pair (STP) will be used for the connection of M12: for the connection of 10Mbps, category 3, 4 and 5 of 100 ohm will be used, and cat.5 of 100 ohm will be used for 100Mbps.
- Page 20 SICOM1005R-M12 User’s Manual 200912 M12-PIN Meaning of PIN PIN1 PIN2 PIN3、PIN4 PGND Figure A-3 Connecting sequence of straight-through cable...
- Page 21 SICOM1005R-M12 User’s Manual 200912 Figure A-4 Connecting sequence of cross-over cable Figure A-5 Connecting sequence of power cable M12 connector installation...
- Page 22 SICOM1005R-M12 User’s Manual 200912...
-
Page 23: Appendix B Cable Type And Specifications
SICOM1005R-M12 User’s Manual 200912 Appendix B: Cable Type and Specifications The cable type and specifications are shown as table B-1: Table B-1 Cable type and specification Cable Type Max. length Connector 10Base-T Cat 3,4 and 5 100 ohm UTP 100m (328 feet) -
Page 24: Appendix C Glossary
Appendix C: Glossary Terminology Explanation Twisted-pair standard of Cat 3, Cat 4 and Cat 5 in IEEE specification for 10Base-T 10Mbps Ethernet Twisted-pair standard of Cat5 or above in IEEE specification for 100Mbps 100Base-TX Fast Ethernet A characteristic that is automatically configured to adaptive mode for the Adaptive speed, duplex and traffic control port. - Page 25 MDI-X Medium Dependent Interface Cross-over...
