Better Solutions Are Within Reach
THIS INSTALLATION SHOULD BE MADE BY A QUALIFIED SERVICE PERSON AND SHOULD CONFORM TO ALL
LOCAL CODES. READ ANDFOLLOW THE SAFETY INSTRUCTIONS BEFORE ATTEMPTING THIS INSTALLATION.
NOTE to CATV system installer: This reminder is provided to call the CATV system installer's attention to Article 820-40
of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be
connected to the grounding system of the building, as close to the point of cable entry as practical.
WARNING:OXYGEN ENVIRONMENT DO
NOT use in an oxygen tent or oxygen
chamber. Such use may cause a fire hazard.
WARNING: To avoid the hazards of fire or
electric shock, DO NOT expose this TV to
rain or moisture.
Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed
on the apparatus. Unplug this unit from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use
a damp cloth for cleaning. This unit REQUIRES periodic maintenance. Refer to the maintenance section for instructions.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do no block any ventilation openings. Install in
accordance with the manufacturer's instructions.
8. Do not install near any heat source such as radiators,
heat registers, stove, or other apparatus (including
amplifiers) that produce heat.
9. Use only with the cart, stand, tripod,
bracket or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination
to avoid injury from tip-over.
10. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
Contact PDi for complete list of approved TV model numbers for which this arm can be used.
PDi Communication Systems, Inc. 40 Greenwood Lane Springboro, Ohio 45066 USA PH 1-800-628-9870 FX 937-743-5664
MODEL NUMBER:
PDI-AA1013 Series Arm
Installation Instruction for 1013 Series Arm
®
DANGER: ARM RECOIL HAZARD The safety
brake pin must remain in the SAFETY BRAKE
PIN HOLE whenever the television set is
removed from the arm or when the arm is
removed from the wall bracket to prevent the
arm from springing open.
with one wider than the other. A grounding type plug has
two blades and a third grounding prong. The wide blade
or the third prongs are provided for your safety. If the
provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
11. Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
12. Only use attachments/accessories specified by the
manufacturer.
13. Unplug this apparatus during lightning storms or
when unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug
is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally,
or has been dropped.
Document Number:
PD196-330R1
Page 1 of 10

Advertisement

loading
Need help?

Need help?

Do you have a question about the 1013 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for PDi 1013 Series

  • Page 1 A polarized plug has two blades or has been dropped. Contact PDi for complete list of approved TV model numbers for which this arm can be used. PDi Communication Systems, Inc. 40 Greenwood Lane Springboro, Ohio 45066 USA PH 1-800-628-9870 FX 937-743-5664...
  • Page 2: Safety Steps

    Remove the PDIPFHMS103238 screw from the PD216-006 base pin cover and set aside for re-installing later. Remove the PD216-006 basepin cover from the top of the wall bracket. Remove the PDI-609 basepin from the wall bracket. PDi Communication Systems, Inc. 40 Greenwood Lane Springboro, Ohio 45066 USA PH 1-800-628-9870 FX 937-743-5664...
  • Page 3 Insert the PDI-609 base pin (end with flats first) thru the top bushing the arm base and the lower bushing. The flats on the base pin must be properly aligned with the Double "D" plate in the bottom of the base for proper installation.
  • Page 4 Proceed to the next step and install the OPTIONAL rotational stop screws, if they are desired. If the rotational stops are not needed, proceed to the step for installing the PD216-006 base pin cover. PDi Communication Systems, Inc. 40 Greenwood Lane Springboro, Ohio 45066 USA PH 1-800-628-9870 FX 937-743-5664...
  • Page 5 Carefully rotate arm against stop to verify travel limit is correct. (2) PDIPFMS1032100 screws and (2) PDINILN1032 lock nuts are provided to allow a rotational stop for both left and right rotation of the arm. PDi Communication Systems, Inc. 40 Greenwood Lane Springboro, Ohio 45066 USA PH 1-800-628-9870 FX 937-743-5664...
  • Page 6 Re-install the PD216-006 base pin cover and secure with the PDIPFHMS103238 screw that was removed during STEP 1. Move the arm from side to side to verify that the arm moves freely. PDi Communication Systems, Inc. 40 Greenwood Lane Springboro, Ohio 45066 USA PH 1-800-628-9870 FX 937-743-5664...
  • Page 7 Make the coaxial cable connection per the installation documents supplied with the LCD TV. After verifying that the LCD TV is correctly connected and functioning properly, begin installing the arm cover kit, Step 7. PDi Communication Systems, Inc. 40 Greenwood Lane Springboro, Ohio 45066 USA PH 1-800-628-9870 FX 937-743-5664...
  • Page 8 (2) PD216-003 Elbow Covers (1) PD216-009L Left Nose Cover (1) PD216-009R Right Nose Cover (8) PD209-004 Painted Cover Screws TV is not shown for installation clarity. PDi Communication Systems, Inc. 40 Greenwood Lane Springboro, Ohio 45066 USA PH 1-800-628-9870 FX 937-743-5664...
  • Page 9 PD196-330R1 PDI-AA1013 Series Arm Installation Instruction for 1013 Series Arm ® Better Solutions Are Within Reach Page 9 of 10 VIEW OF COVER KIT INSTALLED PDi Communication Systems, Inc. 40 Greenwood Lane Springboro, Ohio 45066 USA PH 1-800-628-9870 FX 937-743-5664...
  • Page 10 Page 10 of 10 ARM MAINTENANCE Very little maintenance should be required for your PDI Arm to give years of trouble free service if the following lubrication and inspection procedures are followed. 1. INSPECTION - Occasionally check the base pin for any evidence of bending or distortion due to a patient using the ARM for assistance in getting in or out of bed or any other misuse.
