STEP 6
Using provided flat head wood
screws, secure brackets to
cabinet door. (See Figure 6)
STEP 7
Now that the cabinet door
is attached, you will be able
to fully adjust the door by
loosening and positioning the
bolts on the side of the door
mount bracket (See Figure 7).
Once the door is aligned
correctly, retighten the 2 bolts
on each side.
STEP 8
Your waste container(s) are
now ready to be installed.
On the single bin units, a rear
basket is provided for extra
storage. (See Figure 8)
4
PART NUMBER 11
Customer Service: 800-626-1126 | rev-a-shelf.com
FIGURE 6
FIGURE 7
FIGURE 8
