Doc. no.MX*-OMP0038-D
PRODUCT NAME
AIR SLIDE TABLE
MODEL / Series / Product Number
MXQ6(A,B)-**Z*
MXQ8(A,B,C)-**Z*
MXQ12(A,B,C)-**Z*
MXQ16(A,B)-**Z*
MXQ20(A,B)-**Z*
MXQ25(A)-**Z*

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MXQ6 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SMC Networks MXQ6 Series

  • Page 1 Doc. no.MX*-OMP0038-D PRODUCT NAME AIR SLIDE TABLE MODEL / Series / Product Number MXQ6(A,B)-**Z* MXQ8(A,B,C)-**Z* MXQ12(A,B,C)-**Z* MXQ16(A,B)-**Z* MXQ20(A,B)-**Z* MXQ25(A)-**Z*...
  • Page 2: Table Of Contents

    Contents 1 . P r o d u c t Sp e c i f i c a t i o n s 1 - 1 Sp e c i f i c a t i o n s 2 . H o w t o u s e 2 - 1 M o u n t i n g 2 - 2 A i r s u p p l y 2 - 3 P i p i n g...
  • Page 3 Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC)*1) , and other safety regulations.
  • Page 4 Safety Instructions Caution 1.The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary. If anything is unclear, contact your nearest sales branch.
  • Page 5: Product Specifications

    1. Product Specifications 1-1 Specifications Model MXQ6 MXQ8 MXQ12 MXQ16 MXQ20 MXQ25 Φ6 Φ8 Φ12 Φ16 Φ20 Φ25 Bore size (mm) Port size M5×0.8 Rc1/8 Fluid Action Double acting Operating pressure 0.15 to 0.7MPa Note 1) Note 2) 0.35 to 0.7MPa (with Endlock) Proof pressure 1.
  • Page 6: How To Use

    2. How to use 2-1 Mounting (1) Mounting of body Three types of installation are available according to the machine or work piece. 1. Side mounting (Body tapped) Maximum Thread depth: Max. thread depth: Model Bolt tightening L1(mm) L2(mm) torque MXQ6 M4×0.7 MXQ8...
  • Page 7 2. Side mounting (Body through hole) Maximum Thread depth: Model Bolt tightening L1(mm) torque MXQ6 M3×0.5 MXQ8 M3×0.5 MXQ12 M4×0.7 11.5 MXQ16 M5×0.8 14.4 MXQ20 M5×0.8 19.3 MXQ25 M6×1 23.5 MXQ6A M3×0.5 MXQ8A M3×0.5 MXQ12A M4×0.7 MXQ16A M5×0.8 12.4 MXQ20A M5×0.8 16.3 MXQ25A...
  • Page 8 (2) How to mount the workpiece 1. Front mounting Maximum Max. thread depth: L Model Bolt tightening (mm) torque MXQ6(A) M3×0.5 MXQ8(A,C) MXQ6B M3×0.5 MXQ12(A,C) MXQ8B M3×0.5 MXQ16(A) MXQ12B M4×0.7 MXQ20(A) MXQ16B M5×0.8 MXQ25(A) MXQ20B M6×1 2. Top mounting Maximum Thread depth(mm) tightening Model...
  • Page 9: Air Supply

    (3) Precautions for mounting ! Caution ① Do not dent and scratch the mounting surface of the body, table and end plate. Damage can cause reduction in flatness, play at the guide and increase in sliding resistance. ② Do not dent or scratch the rolling surface of the table. Play or increased sliding resistance can result.
  • Page 10: Piping

    2-3 Piping ! Caution ① Before piping Before piping, perform air blow (flushing) or cleaning to remove any cutting chips, cutting oil, dust, etc. from the piping. ② Sealant tape Wrap this When installing piping or a fitting into a port, way.
  • Page 11: Speed Adjustment

    2-6 Speed adjustment ! Caution Piston speed should be controlled gradually from low speed to the specified speed with a speed controller. 2-7 Handling of optional adjuster ! Caution ① When replacing the bolt, do not replace it with a bolt other than the designated adjust bolt. Impact force may cause play, damage, etc.
  • Page 12 ● Metal stopper with bumper ① Please refer to the table for the Lowest Operating Pressure for a metal stopper with damper. If the operating pressure is lower than this, repeatability becomes worse. Lowest Operating Pressure for metal stopper with damper: The lowest required pressure to fully compress the protruding portion of the damper and have metal to metal contact.
  • Page 13 2-8 Handling of optional functions ●With end lock ! Caution ① The weight of the workpiece shall be maximum load mass or less. Load exceeding the maximum load mass can cause locking failure or the damage of the end lock mechanism.
  • Page 14 ● With buffer mechanism ! Caution ① Use air slide table with buffer in positions below. In horizontal operation, the buffer moves when operation starts depending on the load and the speed, starting the auto switch. Adjust the speed per load. Buffer auto switch: Please refer the table below for proper stroke end detecting position.
  • Page 15: Handling Of Symmetrical Type

    2-9 Handling of symmetrical type ! Caution Space 3mm or more when placing standard type and symmetrical type side by side. If there is not sufficient space between the adjusters, the auto switch may malfunction. 2-10 Mounting of auto switch Precautions for mounting !...
  • Page 16 ④ Please refer the table below for proper mounting position of the auto switch (when the stroke end is detected). For the setting of the auto switch, make adjustment checking the actual operating condition. Solid state switch E Stroke Model Stroke MXQ6(A) MXQ8(A,C)
  • Page 17 Solid state switch E Stroke Model Stroke MXQ6(A) 14.6 17.6 19.6 19.6 MXQ8(A,C) 11.9 11.9 11.9 11.9 11.9 11.9 19.1 19.1 19.1 25.1 42.1 19.1 MXQ12(A,C) 14.5 14.5 14.5 14.5 14.5 14.5 14.5 28.1 20.1 20.1 28.1 28.1 47.1 47.1 MXQ16(A,C) 18.6 18.6...
  • Page 18: Maintenance

    3. Maintenance 3-1 Precautions for maintenance ! Warning (1) Maintenance should be performed according to the procedure indicated in the Operation Manual. Improper handling can cause damage and malfunction of equipment and machinery. (2) Removal of equipment, and supply/exhaust of compressed air When components are removed, first confirm that measures are in place to prevent workpieces from dropping and/or equipment running away, etc.
  • Page 19: Construction/Parts List

    3-3 Construction/Parts list Component parts Description Material Note Body Aluminum alloy Hard anodized Table Stainless steel Heat treatment End plate Aluminum alloy Hard anodized Guide block Stainless steel Heat treatment Cover Synthetic resin Cover support Stainless steel Return guide Synthetic resin Stainless steel MXQ6(B),8(B,C),12(B,C) had a magnet on one side.
  • Page 20 With buffer With end lock Axial piping type Buffer type / Component Description Material Note End plate Aluminum alloy Hard anodized Collar spring Stainless steel Head cap Stainless steel Spring Stainless steel Magnet Rare earth Washer Stainless steel End lock type/ Component Description Material Note...
  • Page 21 Revision history 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 http://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © 2008 SMC Corporation All Rights Reserved...
