- Page 1 Kit Instructions Wall Mount 7197-K100 Issue A...
- Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR office for information that is applicable and current.
-
Page 3: Revision Record
Revision Record Issue Date Remarks Mar 2018 First Issue... - Page 4 Ensure cables are connected to their respective ports on the printer before fastening the wall mount plate. For more information, refer to Connecting the Cables on NCR 7197 Thermal Receipt Printer Series II Owner’s Manual (B005-0000-2068). M3x8 screws...
- Page 5 5) Prepare the installation site. Mount the M5x20 Removal Procedure screws or wall plugs on the wall using the recommended dimensions shown on the sketch 1) Reverse the installation procedure. at the bottom. Properly fasten the screws or plugs to the wall stud. Note: When removing the wall mount paper guide, 6) Attach the printer to the wall.
